Made in China Design in Swiss Laser Cutting Machine Eastern

Name: Made in China Design in Swiss Laser Cutting Machine Eastern
Brand: Bodor
Price: USD $80,000 - 150,000 / Set

FOB Price

USD $80,000 - $150,000 / Set

1 Set(Min.Order)

Supply Ability 200 Set / Sets per Month
Port qingdao tianjin shanghai ningbo
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Place of Origin:	Shandong, China	Brand Name:	Bodor
Model Number:	BCL-FB	Voltage:	220V	Certification:	CE,SGS,FDA
Warranty:	2 years	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

Laser Cutting Machine Eastern

Product Description

Main Features

BCL-FB Fiber sheet metal laser cutting machine adopts most sophisticated fiber laser, combining self-design Gantry CNC machine and high strength welding body. After high temperature annealing and precision machining by large CNC milling machine, it has good rigidity and stability with imported high precision and fast speed, linear guide drive. Aluminum beam, advanced heat treatment process, high strength, light weight, good rigidity. It is mainly for cutting sheet metal below 6mm in high speed and high precision. Fiber laser has a series of advantages, such as high beam quality, high brightness, high conversion rates, maintenance-free, stable and reliable operation of low cost and small size, etc. Air-assisted cutting is the most advanced level of laser cutting, which is particularly suitable for stainless steel, alloy steel, copper, titanium and other metal materials' precision cutting. It is widely used in metal products, hardware, precision machinery, auto parts, glasses, jewelry, nameplate, electronics, toys, advertising and other industries.

Advantage of Fiber laser cutting machine:
1. Excellent path quality: Smaller laser dot and high work efficiency, high quality.

2. High cutting speed: cutting speed is 2-3 times than same power CO2 laser cutting machine.

3. Stable running: adopt top world import fiber lasers, stable performance, key parts can reach 100,000 hours;

4. High efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, fiber laser cutting machine have three times photoelectric conversion efficiency.

5. Low cost: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine.

6. Low maintenance: fiber line transmission no need reflect lens, save maintenance cost;

7 Easy operations: fiber line transmission, no adjustment of optical path.

Technical Parameter

Model	BCL 1530FB	BCL 1540FB	Option
Max cutting range	1500*3000mm	1500*4000mm	According to Demands
Machine Size(LengthWidthHeight)	2.44.71.9m	2.45.71.9m
Accessory Parts(LengthWidthHeight)	Chitler 111.2m Control Box 10.81.8m Fiber Module 0.50.60.14m
Laser Medium	SingleCoreJunctionSemiconductorModule
Max Cutting Speed	25m/min
Cooling Way	Water Cooling
Laser Power	500W(Option 200W/300W/400W/1000W/2000W)
Min line width	0.1nm
Cutting Depth	0.2-6mm
Driving and transmission Way	Imported Servo Motor and Linear Guide Rail
Power Requirements	380V/50Hz/16A
Continuous Working Time	24Hours
Related Weight	Machine Body 2732kg Trolley 116kg Computer Cabinet 56kg Servo Cabinet 75kg Transformer 77kg Chiller 93kg Fiber Module 50kg

Sample

Packaging & Shipping

Package

Contact Us

Jinan Bodor CNC Machine Co., Ltd.: Contact nameSally Geng; Phone86-0531-88690051; AddressHuaya Industrial Park, No. 1881, Kanghong Road, High-Tech Zone
