Specifications
1.MINI FOR ALL Super slim hid ballast2.H4 ALL IN ONE Easy startup xenon kit
3.Stable performance xenon kit
H4 All In One Kit Mini for All
HID mini kit
1) Lightness and thinnest
2) Smallest size
3) Easiest to install
4) Best fit for DIY
Specifications
Product Name: All in one HID car light hid kid
Bulb Model: 9005/9006/H3/H4/H8/H9/H11 all-in-one car light Single Beam
Bulb Color: 3000K,4300K, 6000K, 8000K, 10000K, 12000K,15000K,25000K.30000K
packing:white package or OEM package, sizeParameter
Item Parameter Remarks
Electric Parameter Efficiency >85%
Output Power 33-35W
Input Voltage ≥ 9V
Working Voltage 9V-32
ax Input Current 6.0-7.5A 12V Start-up
Stable Current 3.1-3.5A 12V Input Voltage
Bulb Voltage 85V± 17V
Bulb Flexible Voltage <5V
Test under high temperature-90degrees Work normally, Current: 3.1-3.5A Low/High Temperature Alternating Chamber
Bulb Voltage Wave form Square
Bulb Working Frequency 320Hz± 5%
Max Output Current <2.3A
Min Output Current <0.25A
Discharge Protection Voltage 400V
Ignition Voltage 16KV-23KV
Stability Time 40-60S Cool Bulb
Working Temperature -40degrees--105degrees
Saving Temperature -40degrees--125degrees
Protecting Performance Bulb Discharge Protecting Yes
Bulb Short Circuit Protecting Yes
Input mixed Collect Protecting Yes
Input Low Voltage Protecting <9V
Input High Voltage Protecting ≥ 17V
Dimension Outside diameter diameter63m
ballast height :17mm
1) Small in size, appropriate for 98% cars, best fit for DIY
2) Light weight,small in size, save freight cost.
3) Bulb is directly inserted into ballast, easy installation
4) Wiring harness is made of silica gel which is soft and durable with features of anti-corrosion, anti-interference, can last for about 10 years.
5) The original waterproof and dustproof structure will not be impacted after all-in-one kit is installed. Sealed effect is as well as that of assembly from original factory.
6) Imported components adopted, with heat conduction on the metal shell
7) Bulb lifespan is 3000hours, ballast lifespan is 6000hours
8) Dedicated waterproof rings used to fix bulb and ballast, more tightness
9) easy installation, no need connecting wiring harness and fixing ballast,
10) 3 years guarantee.
Big Big Save in shipping cost:
Let's take an example.
Normally the box size of HID traditional kit is 32x22x7cm, when you order a 20 feet container, there are roughly 4500sets/container.
The box size of HID mini kit is 17x15x6cm, there are roughly 14000sets/container, over 3 times as the traditionl one.
OTHER HID WITH CANBUS:
CANBUS Ballast Features:
1. Cold light low current, quick start light
2. Intelligent start, no impact on light bulb, prolong the life more than three times
3. Intelligent power compensation, stable brightness output
4. Low pressure drop power, safety protection original car circuit
5. Fewer Components, less consumption, high efficiency, low temperature and low failure rate
6. With CAN-BUS design, fully inhibit transmission, radiated interference. Never interfere with the original car appliance
7. Installed directly on any car models, without any auxiliary decoder.
Production workflow chart
Features of HID xenon lamp:
1) Three times brighter than halogen lamp
2) Waterproof, dustproof,shockproof
3) Great luminance and low power consumption
4) More than 10 times longer lifespan than traditional halogen lamp
5)Easy installation :Only need to insert the xenon lamp into the hole of the original light,fixed the ballast,connect and have the cable,and does not need to change the original part of vehicle.
HID lamp’s color temperature and color:
Ballast
HID Conversion Kit includes:
1) One pair of bulbs, Buyer chooses any Bulb type and Color Temperature, 3000K ~30000K
2) Two ballasts, Digital ballasts 35W, 55W, 75W
3) A bag of Brackets and screws
4) installation instruction Booklet , Package box
Super Slim Ballast
Normal Ballast
Workshop
Factory
Please kindly contact us for further information about the HID products.
