Keyland Laboratory Solar Panel Laminator
Semi Solar Module Laminator area:
500mm*500mm(semi automatic type)
2200mm*1100mm (Semi-automatic type)
2200mm*2200mm(Semi-automatic typ
2200mm*3600mm( full-automatic type)
Solar Laminator to laminating glass, EVA (Ethylene Vinyl Acetate Sheet), solar cell and back sheet.
Spec. of Solar Laminator :
Power:AC380V 3 Phase five line | |
Mode of heating |
Electric |
Degree of vacuum |
200----20Pa |
Way of temperature control |
PLC Intelligent Temperature Control |
Laminated cavity height |
20mm |
Compressed air pressure |
0.6----1.0MPa |
Evacuation time up to operating pressure |
5----6 minutes |
Control way |
Touch screen |
Control Method |
AUTO/MAN |
Lid height |
Max 500mm |
Temperature control precision |
≤±1°C |
Temperature uniformity |
±1.5°C |
Compressed air flow |
0.42-0.8m³/min |
Laminating time |
2----4 minutes |
Operation & Control
Pneumatic lifting structure, and stable running with little noise
Stable structure designed for long time working with high temperature.
Touch screen with international brand, and hi-tech PLC control
High Performance
Electric heat cycling and professional electric heating system with stable and uniform temperature
Good performance vacuum system with international brand
Three-phase laminating design with high module yield
High quality and super-strong mechanical structure design, and area saving
Main Specification Parameter
Laminating Area |
Temperature Uniformity |
Temperature Precision |
Power |
Temperature Range |
Weight |
Air Supply |
500×500mm |
±2 °C |
±1 °C |
6.5KW |
30~160°C |
300KG |
0.6~1.0MPa |
Our Semi Solar Module Laminator is sutable for solar panel production line or Lab:
Ready material carrier
Module transfer carrier
Laying upstation
Inspection station
Trimming table
Cleaning table
Our wararnty:
