Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Cutting Machine > High Performance 20w Fiber Laser Silicon Wafer Laser Cutting Machine
High Performance 20w Fiber Laser Silicon Wafer Laser Cutting Machine
US$ 9,500 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
Fiber Laser
Applicable Material:
Other, Silicon Wafer
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KEYLAND Broken Silicon Wafer CNC Scribing With Negative CutUS$ 9,000 - 15,000MOQ: 1 Set -
Keyland Fine Edge Laser Cutting Machine for PV CellsUS$ 9,000 - 15,000MOQ: 1 Set
-
Water Cooling 50 Watt Semiconductor Diode Solar Cell Laser Cutting MachineUS$ 9,500 - 10,000MOQ: 1 Set
-
WUHAN KEYLAND Solar Cell Semiconductor Fiber Scribing Machine, Solar Cell Laser Scriber for Cutting Solar CellsUS$ 5,000 - 9,500MOQ: 1 Set
-
Keyland Laser Cutting Silicon Solar Cells MachineUS$ 9,000 - 15,000MOQ: 1 Set
Condition
New
Laser Type
Fiber Laser
Applicable Material
Other, Silicon Wafer
Cutting Thickness
1.2 mm
Cutting Area
340 x 340 mm
Cutting Speed
300 mm/s
CNC or Not
No
Cooling Mode
Air Cooling
Control Software
Keyland Laser Cut
Graphic Format Supported
AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Place of Origin
Jiangsu, China
Brand Name
Keyland
Model Number
GSC20
Certification
CCC, CE, GS, ISO, SGS, UL
After-sales Service Provided
Engineers available to service machinery overseas
High Performance 20w Fiber Laser Silicon Wafer Laser Cutting Machine
Features
- Auto vacuum worktable.
- Lower cost compared to fiber laser.
- High precision motion system: Panasonic servo motor + screw rod.
- Powerful software easy to operate with cutting path preview.
- Foot-switch control
Specs
| Model | GSC-10F | GSC-20F |
| Laser source | Fiber | |
| Output power | 10W | 20W |
| Wave length | 1064nm | |
| Scribing line width | 30μm | |
| Max scribing speed | 300mm/s | |
| reposition accuracy | ±10um | |
| Laser pulse frequency | 20kHz-100kHz adjustable | |
| The laser pulse width | 25ns | |
| Work table | Auto vacuum 350x350mm / 14"x14" |
|
| Power supply | 220V, 50Hz, 1kVA | |
| Cooling way | Air cooling | |
Machine Photos
Work sample
DEMO VIDEOS
(copy the link to a new tab to watch)
| Solar cell scribing | http://youtu.be/j8coMUMP5Qs |
Company View
Why Buy From Us?
Doing business with KEYLAND is SAFE and BENEFICIAL.
- Alibaba Trade Assurance
- Onsite Checked by BV
- Golden Suppliers for Years
- CE, ISO, FDA approved products
- Warranty Up To 2 Years
- Full Operator Training & Support
How to Contact Us?
More details about our Silicon Wafer Laser Cutting Machine please contact us.
