Keyland Semi Automatic Solar EVA TPT Cutting Machine for Solar Panel Making Line
Solar EVA TPT cutting machine is suitable for Solar Panel Making Line EVA TPT cutting with
Auto feeding deivce:
*Driver :Use Low speed motor with turbine housing for feeding mechanism.
* Combined with the special structure of TPT EVA automatic feeding
Automatic cutting :
*TPT use rodless pneumatic cutting knife roll
*EVA high-speed motor with blade cutting
Automatic counting
Automatic Positioning and etc function.
Materials: Steel Struction
Control way :Mechatronics Control
Semi-automatic production, improve cutting efficiency, reduce labor intensity, provide economic benefits
| Item | Spec |
| Power supply voltage | Three phase four wire |
| Max.cutting length | 2000mm |
| Max. Cutting Width | 1000mm |
| Phase unbalance rate | 5.5%~7% |
| Counter Range | 0-9999times |
| Cutting Speed | 1.5s/times |
| Power | 1.5KW |
| Weight | 800kg |
| Size of machine | 3000mm*1600mm*800mm |
Jiangsu KEYLAND solar panel assembly line machines surplus
Warmly welcome to contact Lucia Lv lucia(@) for more details
Following is step by step of Solar Panel Assembly Line .
|
Solar Cell Teser Model:GTC-AAA Lamp Spectrum:IEC60904-9 JISC8933 Light-intensity:100mW/cm2(20-120mW/cm2 Light intensity non-uniformity≤±3% Instability degree of irradiation≤±2% Test result-consistency≤±1% Test error of electrical properties≤2% Single flash time:10ms~30ms Effective Test range200×200mm/0.1W-5W Measuring voltage0-0.8V(resolution 1mV) Measuring current0-20A(resolution 1mA) Test-Parameters:IscVoc.Pmax.Vm.Im.FF.EF.Temp.Rs.Rsh |
|
Fiber Laser scribing mc for Solar Cells Model:GSC-20 Laser wavelength:1064nm Scribing width:30um Scribing Speed:300mm/s Scribing accuracy:±10um Working area:350*350mm Cooling way:Air Cooling |
|
Semi-automatic Solar Laminator (full Automatic for option) Model KL-2222 Size of laminate(m)2.2*2.2 Heating mode:By oil Safty and alarming system Temperature control:PLC control Temperature Accuracy:±1C |
|
PV EL Tester for micro crack (automatic type for option) Model:KL-EL610 Effective testing area1200×2100mm Resolution:6.1megapixels Sensitivity:Can detect crack width less than0.2μm Testing time:1s—60s set freely Configuration-Testing-platform(including-infrared camera),computer,Professional software |
|
Solar Simulator (Automatic Type) Model:GTM-ABB-2012 Lamp Spectrum:EC60904-9/ JISC8933[A ] Light-intensity:100mW/cm2(20-120mW/cm2 adjustable) Light intensity non-uniformity≤±3% Instability degree of irradiation≤±2% Test result consistency±1% Test error of electrical properties≤2% Single flash time:10~30ms Effective Test range:2000×1200mm/5W~300W Measuring voltage:0-100V (resolution 1mV) Measuring current:0-20A (resolution 1mA) TestParameters:Isc.Voc.Pmax.Vm.Im.FF.EFF.TempR,Rsh |
|
Solar Panel Framing Machine(semi-automatic) Max. Framed Dimensions :2000*1200*(35~30)mm Min. Framed Dimensions :200*180*(35~30)mm Framing precision:1mm Diagonal size of the difference:±1.5mm Square angular deviation:±0.5 Driving force of frame:Pneumatic, hydraulic Working Pressure:0.4Mpa~0.7Mpa Size of mc:2.9*1.9*0.97m Hydraulic Pressure:1.0 Mpa~15Mpa |
|
Welding station (1string +2 single) Aluminum Extruded sections Three workplace: 1 string welding and 2 single welding No conveyor belt outer dimension:2.1*1.2*1.8m Configuration including: 2PCS single welding heating template String welding heating template 156 string welding template Temperature electric cabinet and exhaust system,light |
|
EVA/TPT cutting station Dimension:2.9*1.22*0.87m Materials: Aluminium 1.The plate surface with scale ruler,easy to control the different size Support EVA TPT ,using of sliding bearings, good flexibility |
|
Lay up Station Aluminum molding structure Dimension:2.32*1.1*0.86m 1.Sprays Special oil, Strengthen light focus ability 2.With ordinary energy-saving lamps,halogen lamp test 3.Can test module electric current ,electric voltage 4.With a tempered glass Electric current voltage can turn automatically |
|
Inspection Station |
|
PV ribbion Cutting machine |
EVE/TPT Carrier |
| Cell String storage station |
| Ready Materials Carrier |
|
Module Carrier Electric Iron |
In order to quote suitable project with competitive price,Would you please let me know some items following?
1. What is your annual production capacity?
2. What size of solar module do you plan to make,big solar module or small one (less than 100W)?
3. How many working hours per day ?
