500w YAG 1mm Gold Laser Cutting Machine for 1mm Gold Cutting Price CE certficate

Plywood Package

Specifications

1mm Gold Laser Cutting Machine
1.High speed 4.5m/min
2.Easy operation
3.Smooth cutting surface
4.1300*2500 1500*3000

  500w YAG 1mm Gold Laser Cutting Machine for 1mm Gold Cutting Price CE certficate







Model:KQG-1325C/KQG-1530C

Features:

1. High accuracy: be suitable for various precision metal cutting;

2. Ball screws and servo motors : Be sure the high efficacy .

3. Small heat affected zone, good dimension stability. Flat and handsome laser-slotted, further process is unnecessary;

4. Steady performance: as a mature laser apparatus, the YAG laser cutting machine is suitable for serial production.

5. Fast speed:100 times higher than traditional linear cutting;

Applicable material:

Stainless steel, carbon steel, alloy steel, spring steel, Aluminum alloy, copper plate, Aluminum plate, gold, silver, Titanium, other metal plates and metal pipes, and so on.

The main technical parameters

Type Specification	KQG-1530C/KQG-1325C
Laser wave length	1064nm
Max. laser power	650W
Chiller	5P
Travel area	1500mmx3000mm
Pulse frequency	1--600HZ
Minimum line width	0.15mm
Working Power	380V/50HZ/100A
Max  speed	moving:6000mm/min; cutting:3000mm/min
Max Cutting thickness	Stainless steel 5mm, Carbon steel 6mm
Suitable materials	Stainless steel, Carbon steel, Aluminium plate, Copper plate, Titanium plate,etc.
Floor space	5x5m
Weight	4000 KG



Laser power:

The internal part of ZGM-SD Model pulse laser power is control by SCM,so it is real numerical controlled power. The user can programme on a variety of laser waveforms and parameters through the keyboard, and thus this laser power can meet the needs of almost all metal welding, and it is the ideal configuration of multi-function laser welding machine..



Water Compressor Chiller:

This water chiller adopt high power 5P water chiller, and it can cool the laser system continuously, adjust the temperature automatically, ensures working for a long time. The temperature of the water can be kept within plus-minus 5 degree. The constant temperature of water can keep the laser power stable, work more steady and fast.



Motors and Drivers:

This system adopted with two 1500W imported Japanese servo motors and drivers, assuring constant and stable movement.



Pneumatic Feeding & Holding:

 The feeding and holding system, which are drived by an air compressor, Thus the customers can work on stainless steel plate easily and accurately.



Germany Technology YAG Generator and Sealed Laser Optic system:

The generator consist of YAG crystal rod,golden chamber,xenon lamp: lifetime of Xenon Lamp is about 500-600 hours, low cost and comparatively economic;Precise and rational design, optical, adjustment for easy lamp and rod replacement



The solid-state laser cutting machine make use of cantilever structure therefore just move beam body to edge during adjustment of laser path, the operator can replace the side lights and rods behind the beam body.



Laser inductive Servo head:

Our solid laser cutting machine uses USA technology auto focusing cutting head. Cutting head laser nozzle locking ring touch the metal sheet materials surface, cutting head move up and down, and it can achieve same focal cutting. The cutting head has high sensitivity, stable running and good reliability.When cutting metal sheet,



Cutting software Interface:

The cutting software can support many formats, such as dxf.,plt.,dsb.,bmp.,png.,ico., cur., tif., tga., pcx., wmf., emf., jbg., pnm., ska., ras.,etc.



Samples show:





Our factory & exhibition:





Guarantee&Aftersales service:

The whole set of machine is guarantees for one year

24 hour technical support by email or calling

User-friendly english manual for machine using and maintaining

User-friendly English manual and Video CD for machine using and maintaining.

Our self-developed English software can do all kinds of pattern recognition.



We also produce



Please know following before your order :



 1.Different price ,different Configuration !



 2.In China, The better quality of laser equipment is main in Wuhan, China Optical Valley.



 3.Price is important, while service is also important for equipment .



Should you have any question, please don't hesitate to contact me .I will guide you more in this field.



Welcome to contact us,we will do our best for you.

distributors wanted for   500w YAG 1mm Gold Laser Cutting Machine for 1mm Gold Cutting Price CE certficate  !!!
