SINO 7CBM steel plate fire truck price

FOB Price

USD $46,000 - $70,500 / Set

1 Set(Min.Order)

Supply Ability 500 Set / Sets per Month
Port any port in China as your request.
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Drive Wheel	4x2	Type	Tanker
Transmission Type	Manual	Condition	New
Horsepower	150 - 250hp	Tank Capacity	7001 - 10000L
Emission Standard	Euro 4	Fuel Type	Diesel
Max. Work Height	1	Size	8785X2490X3350
Place of Origin	Hubei, China	Brand Name	Sinotruck
Model Number	ZZ1166M4616C1

Product Description

SINO 7CBM steel plate fire truck price

Product Description

SINO HOWO 4X2/4X4 8CBM water tank fire truck dimension from China

1. We are the manufacturer.

2. OEM is OK.

3. ISO certificate.

Main Specifition

Technical parameters for SINO 7CBM steel plate fire truck price
The totalmass(kg)	19000	Curb Weight(kg)	10550
Rated the quality of(kg)	8000	Chassis Model	ZZ1166M4616C1
Approach / departure angle(°)	17/11	Front overhang / rear overhang	1560/2625
Dimensions(mm)	8785X2490X3350	Compartment dimension(mm)
Number of axes	2	Maximum speed	85
Tire Specifications	11.00-20,11.00R20	Number of tires	6
Front track	1939,1958	Rear track	1800,1830
Wheelbase	4600	Axle load	6000/10000
Number of spring	9/9+6	Type of fuel	Diesel
Emission Standards	EuroIV
Engine parameters
Engine Model	WD615.92E	Engine Manufacturer		Sinotruk
Engine Displacement	9726	Engine power		196
Chassis Description	1,Sinotruck 4x2 chassis,flat and crew cab , left/right hand drive ,AC; 2,300HP,6 cylinder diesel engine , emission standard Euro III/IV, 10 shift gearbox ; 3,10 ton double rear axle , gas brake , power steering
Modified Description	1,Fire fighting truck:fire-extinguishing water tanker,fire-extinguishing foam tanker,water-foam fire fighting truck, emergency rescue fire truck and ect. 2,Equipped with fire pump,PTO,storage compartment,long-line lights and fire monitor.
Composition	Basic composition:chassis,fire pump,PTO,storage compartment,long-line lights and fire monitor,fire fighting tools and ect.
Application	Fire fighting truck is specially used for fire fighting vehicles or other emergency rescue purposes. This truck can be devided into pump truck(water supple vehicle sprinkling water or fire), aerial(high save) and other special vehicles by its function.
Product advantage	reasonable price,multiple functions,easy operation

Water Tank Fire truck Function Parameter
Fire Pump	model		CB20.10/20.40-XZ
	flow at low pressure (L/s/r/min)		40(3070)
	flow at medium pressure (L/s/r/min)		20(3150)
	Output pressure at low pressure		1

	Output pressure at medium pressure		2

	Priming device	Priming pump type	reciprocating primer pump

		Priming time	≤35

		Max suction	7

		Max Vacuum	≥85

		Delta pressure decreasing within 1 minute	≤2.6

Monitor	model		PS40W
	work pressure (MPa)		1
	flow(L/s)		30
	Rated range (m)		≥55

Accessory Diagram
