Home > Products > Fire Fighting Truck > SINO HOWO6X4 15T water tank fire truck with water tanker
SINO HOWO6X4 15T water tank fire truck with water tanker
USD $47,000 - $85,000
/ Set
1 Set(Min.Order)
- 500 Set / Sets per Month
- any port in China as your request.
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
The Mercedes-Benz Arocs 18-ton foam fire and rescue truck.
-
The Euro III emission standard Heavy Truck WoWo 11-ton dual-purpose dry powder and foam fire truck
-
Isuzu's 3.5-ton water tanker fire truck, the guardian of the city's flames
-
Howo 12-ton foam fire truck, a professional choice for emergency management departments and petrochemical enterprises
-
Heavy truck HOWO 8t water tank foam fire truck
-
Dongfeng Tianjin 12-ton water tank fire truck: Guardian of Life
Product Details
| Drive Wheel: | 4x2 | Type: | Tanker | Transmission Type: | Manual |
| Condition: | New | Horsepower: | 251 - 350hp | ||
| Emission Standard: | Euro 4 | Fuel Type: | Diesel | Max. Work Height: | 1 |
| Size: | 10025x2500x3600 | Place of Origin: | Hubei, China | Brand Name: | Sinotruck |
| Model Number: | ZZ1257 |
Product Description
SINO HOWO6X4 15T water tank fire truck with water tanker
Product Description
SINO HOWO6X4 15T water tank fire-fighting truck
1. We are the manufacturer.
2. OEM is OK.
3. ISO certificate.
Packaging & Shipping
| Packaging Details: | Nude/ Ro-ro ship / Bulk transport / Container packing / SKD / etc. and it can be offered according to your request. |
|---|---|
| Delivery Detail: | 10 to 25 days after receiving your deposit by T/T & L/C. |
Main Specifition
| Technical parameters | ||||
| The totalmass(kg) | 27600 | Curb Weight(kg) | 14800 | |
| Rated the quality of(kg) | 12350 | Chassis Model | ZZ1257M4647C | |
| Approach / departure angle(°) | 16/13 | Front overhang / rear overhang | 1500/2490 | |
| Dimensions(mm) | 10025×2500×3600 | Compartment dimension(mm) | ||
| Number of axes | 3 | Maximum speed | 102 | |
| Tire Specifications | 11.00-20,12.00-20 16PR11.00R20 16PR,12.00R20 14PR | Number of tires | 10
| |
| Front track | 2022,2041 | Rear track | 1830/1830 | |
| Wheelbase | 4600+1350,4575+1400 | Axle load | 7000/18000 | |
| Number of spring | 10/12,4/12,10/- | Type of fuel | Diesel | |
| Emission Standards | Euro III/Euro IV | |||
| Engine parameters | ||||
| Engine Model | WD615.92 | Engine Manufacturer | China National Heavy Duty Truck Group Co., Ltd. | |
| Engine Displacement | 9726 | Engine power | 196 | |
| Chassis Description | 1,Sinotruck 6x4 chassis , flat and crew cab ,left/right hand drive with A/C; 2,Weichai Power 336hp diesel engine , 6 cylinder , Euro III/Euro IV emission standard ,9/10 shift gearbox; 3,13 ton rear double axle , gas brake , power steering; | |||
| Modified Description | 1,Fire fighting truck:fire-extinguishing water tanker,fire-extinguishing foam tanker,water-foam fire fighting truck, emergency rescue fire truck and ect. 2,Equipped with fire pump,PTO,storage compartment,long-line lights and fire monitor. | |||
| Composition | Basic composition:chassis,fire pump,PTO,storage compartment,long-line lights and fire monitor,fire fighting tools and ect. | |||
| Application | Fire fighting truck is specially used for fire fighting vehicles or other emergency rescue purposes. This truck can be devided into pump truck(water supple vehicle sprinkling water or fire), aerial(high save) and other special vehicles by its function. | |||
| Product advantage | reasonable price,multiple functions,easy operation | |||
| Water Tank/Foam Fire truck Function Parameter | |||
| Fire Pump | model | CB20.10/20.40-XZ | |
| flow at low pressure (L/s/r/min) | 40(3070) | ||
| flow at medium pressure (L/s/r/min) | 20(3150) | ||
| Output pressure at low pressure | 1 | ||
| Output pressure at medium pressure | 2 | ||
| Priming device | Priming pump type | reciprocating primer pump | |
| Priming time | ≤35 | ||
| Max suction | 7 | ||
| Max Vacuum | ≥85 | ||
| Delta pressure decreasing within 1 minute | ≤2.6 | ||
| Foam mixer | PH32 | ||
| Monitor | model | PL24 | |
| work pressure (MPa) | 1 | ||
| flow(L/s) | 24 | ||
| Rated range (m) | water ≥50,foam ≥40 | ||
Accessory Diagram
