Galvanized Masonry Ladder / Truss Wire Mesh

Name: Galvanized Masonry Ladder / Truss Wire Mesh
Brand: Huade
SKU: 119294051

US$ 0.1 - 3 MOQ: 20 Tons

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

Huade

Model Number:

HD-Building material, HD-Building material

Anping Huade Hardware & Mesh Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name Huade

Model Number HD-Building material, HD-Building material

Material Other, Steel, Q235 / S235

Specifications

Galvanized Masonry ladder / Truss wire mesh
Width:5/10/15cm
Space:40cm
Ideal for Brick Construction
Manufactu

Galvanized Masonry ladder / truss mesh/ Block reinforcement mesh

Used in Building Surface, Wall, Ground and Bridge.
Customized specifications and sizes are available.

Masonry horizontal joint reinforcement mesh include ladder-type and truss type. Ladder type

reinforcements are designed to be embedded in the horizontal mortar joints of masonry walls. It

consists of two parallel side rods with cross rods welded at 16” (400 mm) O. C., thus forming a

ladder configuration. Overall measurement (side-to-side rod) is approximately 2” (50 mm) less

than the nominal wall thickness.truss type reinforcement designed to be embedded masonry wall.

It consists of 2 side-rods welded to a continuous diagonal formed cross-rod forming a truss design

with alter nating welds not exceeding 8” (200 mm) O. C. overall. For use in single-wythe walls.

Standard Length	Width	Finishes
10’(3.05m)	2”(50mm)	Uncoated Electro Galvanized Hot Dipped Galvanized After Fabrication Stainless Steel
	4”(100mm)
	6”(150mm)
	8”(200mm)
	10”(250mm)
Wire gauge: from 2mm-6mm Package: 20 pcs per carton/bundle or carton/pallet/plastic wrapped
