Hot sell mini cnc press brake

Name: Hot sell mini cnc press brake
Brand: MEILI
Price: Negotiable

FOB Price

Negotiable / Set

1 Set(Min.Order)

Product Details

Place of Origin:	Jiangsu, China	Brand Name:	MEILI	Model Number:	Y31
After-sales Service Provided:	Engineers available to service machinery overseas

mini cnc press brake
1.simple operation
2.two kinds of operations
3.various process uses

Hot sell mini cnc press brake

Type		Unit	2.5T	4T	6.3T	10T	16T	25T	40T
Nominal force		KN	25	40	63	100	160	250	400
Max pressure of liquid		Mpa	5	7.9	8	8.1	13	20.3	25
Max opening height		MM	300	390	450	500	550	600	600
Ejector force		KN							63
Table size	F.B	MM	400	400	400	400	450	450	450
Table size	L.R	MM	400	400	400	400	400	400	400
Ejector Stroke		MM							120
Slide speed	Idle stroke down	MM/S	42	45	45	45	45	45	42
	Working	MM/S	0-42	0-45	0-45	0-45	0-45	0-45	10
	Return	MM/S	77	77	81	81	80	80	70
Outline dimensions	L.R	MM	560	560	580	650	650	750	1484
	F.B	MM	725	780	935	1100	1140	1200	1350
	Height	MM	1450	1630	1675	1800	1800	2100	2406
Table height above the floor		MM	700	710	700	710	710	710	700
Diameter of blank-holding hole		MM	70	70	80	80	100	100	100
Motor power		KW	2.2	2.2	3	4	5.5	5.5	5.5
Total weight		T	0.5	0.75	1	1.3	2	2.3	2

Wuxi Meili Hydraulic Pressure Machine Factory: Contact nameSophia Zhang; Phone86-510-83500837; AddressNo. 18, YanYu Road, Qianzhou Fitting Zone, Huishan Economic Development Zone Wuxi,Jiangsu
