Help Center200ton Excellent Quality Hydraulic Press Used for Workshop
Related Products
-
Meili Best Selling Cheap 150 Ton Hydraulic PressUS$ 999.00 - 999.00MOQ: 1 Set -
Single Column Single Pillar Hydraulic Press Machine 100 TonUS$ 7,280 - 42,800MOQ: 1 Set
-
CNC C Frame Professional Factory 60 Ton Hydraulic PressUS$ 999.00 - 999.00MOQ: 1 Set
-
BEST CHOICE!!! Used Hydraulic Press MachineNegotiableMOQ: 1 Set
-
Direct Factory Hydraulic Press for Rubber VulcanizationUS$ 999.00 - 999.00MOQ: 1 Set
Dedicated to tensile, bending, sheet metal formig processes, blanking, correcion pressing, punching. Suitable for automotive, aerospace and chemical industries need.
Following are the specifications
Model |
Y28-100T/160T |
Y28--200T/315T |
Y28-315T/515T |
||
Specification |
Unit |
Parameters |
|||
Rated force |
KN |
1600 |
3150 |
5150 |
|
Drawing force |
KN |
1000 |
2000 |
3150 |
|
Pressing force |
KN |
300*2=600 |
575*2=1150 |
1000*2=2000 |
|
Pressing slide return force |
KN |
140 |
240 |
460 |
|
Eject force |
KN |
200 |
280 |
630 |
|
Max. hydraulic pressure |
Mpa |
25 |
25 |
25 |
|
Max. drawing slide shut height |
mm |
900 |
900 |
1150 |
|
Max. pressing slide shut height |
mm |
500 |
600 |
750 |
|
Max. drawing slide stroke |
mm |
450 |
450 |
600 |
|
Max. pressing slide stroke |
mm |
400 |
450 |
550 |
|
Ejection stroke |
mm |
200 |
200 |
250 |
|
Drawing slider |
L-R |
mm/s |
800 |
1120 |
1400 |
F-B |
mm/s |
800 |
1000 |
1400 |
|
Pressing slider |
L-R |
mm/s |
800 |
1120 |
1400 |
F-B |
mm/s |
800 |
1000 |
1400 |
|
Drawing slider speed |
Idle stroke |
mm/s |
150 |
150 |
150 |
Pressing |
mm/s |
9-20 |
9-20 |
7-15 |
|
Return |
mm/s |
145 |
140 |
105 |
|
Pressing slider speed |
Idle stroke |
mm/s |
150 |
150 |
180 |
Pressing |
mm/s |
30 |
32 |
23 |
|
Return |
mm/s |
125 |
120 |
100 |
|
Work table Size |
F.B. |
mm |
800 |
1120 |
1400 |
L.R. |
mm |
800 |
1000 |
1400 |
|
Main motor power |
kw |
14 |
18 |
26 |
|
Voltage |
380V, 50Hz, 3 Phase |
||||
Operating Temperature |
℃ |
0-40 |
|||
Total Weight(Approx) |
KG |
8000 |
14500 |
31500 |
|
Certifications:
