Home > Metallurgy, Mineral & Energy > Solar & Renewable Energy > Solar Cell > 200w All Black Mono Solar Modules With 72 Pcs 125*125 Mono Cells With CE, TUV, UL, CSA, MCS PV CYCLE
200w All Black Mono Solar Modules With 72 Pcs 125*125 Mono Cells With CE, TUV, UL, CSA, MCS PV CYCLE
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
JS
Model Number:
JS200BD
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mono Solar Panel Price With 250W Black PanelNegotiableMOQ: 50000 Watts -
Mono Black Solar PanelsNegotiableMOQ: 1
-
Black ModulesNegotiableMOQ: 1 Piece
-
Solar PanelNegotiableMOQ: 1
-
190w All Black Mono Solar Modules With 72 Pcs 125*125 Mono Cells With CE, TUV, UL, CSA, MCS PV CYCLENegotiableMOQ: 1
Place of Origin
Jiangsu, China
Brand Name
JS
Model Number
JS200BD
Material
Monocrystalline Silicon
Size
1580mm*808mm*35mm
Number of Cells
72cells
Max. Power
200W
Specifications
Please check the detailed specifications as follows:
Electric Characteristics(STC)
Type JS200BD
Nominal Power(Pmax)[W]: 200
Voltage at Pmax(Vmp)[V]: 37.1
Current at Pmax(Imp)[A]: 5.38
Open Circuit Voltage(Voc)[V]: 45.4
short circuit Current(Isc)[A]: 5.77
Power Tolerance[%]: 0-3
Maximum System Voltage[V]: 1000
Module Efficiency[%]: 15.7
Specifications
Dimension A*B*C(mm): 1580*808*35
Weight(kg): 16.8
Cable Length(mm): 900
Type of Connector: MC4
Product Guarantee
25-year linear performance warranty
10-year warranty on materials and workmanship
