Big Spindle Bore CNC Pipe Lathe CKG260/2000,3000

Name: Big Spindle Bore CNC Pipe Lathe CKG260/2000,3000
Brand: SIMEX
SKU: 119238529
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Shaanxi Simex Enterprise Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI PORT CHINA

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 900MM

Place of Origin China

Brand Name SIMEX

Model Number CKG260

Voltage 380V/50HZ/3 PHASE

Power(W) 18.5 KW

Weight 4100/4600 KGS

Certification ISO 9001

After-sales Service Provided Engineers available to service machinery overseas

BIG SPINDLE BORE CNC PIPE LATHE CKG200/2000,3000 SPECIFICATION:

PRODUCT FEATURES:

· The surface of the bedways is supersonic frequency hardened and precision ground with a long service life

·The spindle system is high in rigidity and accuracy

· Longitudinal and cross feeds are effected by ball leadscrews.

·Chuck arrangement both at front end and rear end secures the stability and reliability

Over bed	Ø900 mm
Over carriage	Ø540mm
Width of bed	560 mm
Max. length of work piece (two centers)	2000/3000 mm
Max. turning length	1800 /2800mm
Outer dia. of turning pipe	Ø70~ Ø260mm
Spindle nose	A₂-20
Spindle bore	Ø270 mm
Steps of spindle speed(Manual)	(VariableWithin Each Step)
Range of spindle speed	10~60,20~115 , 35~205,65~380 r/min
Rapid feed for Axis Z	10m/min
Rapid feed for Axis X	5 m/min
Max. travel of Axis X	500mm
Max. travel of Axis Z	1850/2850mm
Min. input	0.001 mm
Tool post stations	4 station
Tool cross section	40×40 mm
External diameter	Ø100 mm
Taper of bore	M.T.NO.6
Max. Traverse	230 mm
X/Z motor torque	20/27Nm
Power of main motor	18.5KW
Power of cooling pump	370W
Overall dimensions(L×W×H)	4560/5560×1918×1860
Net weight	4100kg/4600kg
