Specifications
10 Head Automatic Weighting and Vertical Packing Machine 1.PLC CONTROL2.Automatic weighting
10 Head Automatic Weighting and Vertical Packing Machine
MAIN COMPONENTS:
- Main Frame 2. 10 heads weighter 3.Z type bucket elevator
- Vibration feeder 5. Supporting platform
It’s suitable to use in packing the high accuracy and easy fragile material, such as : puffy food, crispy rice, jelly candy, pistachioapple slices, dumpling, chocolate, medicine, pet food, small hardwares etc.
AUTOMATIC VERTICAL PACKAGING MACHINE
SPECIFICATION:
Max.width of roll film |
420mm |
Bag length |
80-300mm(L) |
Bag width |
50-200mm(W) |
Packaging rate |
50-250bag/min(depends on the size) |
Measuring range |
150-1200ml |
Power voltage |
220V/2.2kw |
Dimension |
(L)1320*(W)950*(H)1360mm |
Weight of machine |
540kg |
10 HEAD WEIGHTER
Measure number |
10 |
Range of single weighing |
50-1000g |
Quantity precision |
0.1-1.5g |
Average tolerance of single bag |
0.2-0.7g |
Hopper capacity |
1300ml |
Net/gross |
300/370Kg |
Overall size |
(L)1400*(W)1130*(H)1120 |
