1. Application:
Thermal shrink packaging machine Model ST6030+SM6040 is a new type of packaging machinery capable of high-efficiency and continuous operation and designed on the basis of thermal shrinkage property of packaging film. It can automatic arrange, group, wrap with shrink film single PET beverage bottle or other similar substances, and turn into assembly package by heat shrinkage and cold setting. Products packaged in this way will be tied up firmly presenting orderly and good appearance, and will be easy to open.
2. Features:
1) Operating through touch screen with friendly interface convenient for man-machine communication and operation.
2) Pallet-free packaging adequate for package of different bottle sizes and in different combinations.
3) With automatic functions of bottle transfer and arrange, membrane packing, sealing and cut, shrinkage, cooling and shaping and so on.
4) Using advanced constant temperature membrane heating binding technology with smooth and secure seal.
5) The quick seal cooling structure guarantee that the seal has a higher strength
6) Adopt with PLC automatic program circulation control with stable and reliable performance.
7) The inductive switch controls the membrane transfer system to reliably adjust and control membrane transfer length with less loss
8) All the transfer system is controlled by frequency changing devices with stable and smooth transfer speed.
The Main Technical Parameters | ||
External Dimension |
L5050*W3300*H2200 |
|
Whole package size |
Main Machine |
L1180*W1080*H2370 |
Thermo-wind Shrink Stove |
L3890*W1050*H2040 |
|
Cabinet |
L1250*W780*H1100 |
|
Total Weight |
1.2T |
|
Max. Packing Size |
L600*W400*H350 |
|
Packing Speed |
8-15 Packages per minute |
|
The speed of Conveyor |
920(Adjustable 200) |
|
Working Power |
3 phases 5lines 380V 20KW |
|
Working Pressure |
0.6-0.8Mpa |
|
Total Power |
20KW |
|
