plastic drinking bottle water machie
semi-automatic bottle blow molding machine
Specification:
semi-automatic bottle blow molding machine is suitable for producing PET plastic containers and bottles from 50-2000ml. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle etc.
Technical parameter:
Name |
Item |
Unit |
Details |
Blowing machine |
Dimension |
mm |
1600*600*1610mm |
Weight |
kg |
500 |
|
Bottle volume (max) |
ml |
2000 |
|
Bottle volume (min) |
ml |
50 |
|
Bottle Neck Diameter (max) |
mm |
40 |
|
Bottle Neck Diameter (min) |
mm |
18 |
|
Body Diameter (max) |
mm |
125 |
|
Body Height( max) |
mm |
420 |
|
Number of Cavities |
mold |
2 |
|
Production output |
pcs/h |
800BPH |
|
Clamping force |
T |
5.756KN |
|
Mold thickness |
mm |
200max |
|
Mold width |
mm |
360x390 |
|
Space between Tie-bars |
mm |
120-220 |
|
Diameter of Tie-bars |
mm |
63 |
|
Scope of Tie-bars |
mm |
405 |
|
Mold stroke |
mm |
160 |
|
Stretching stroke (max) |
mm |
420 |
|
Working pressure |
Mpa |
0.8-1.0Mpa |
|
Blowing pressure |
Mpa |
2.0-3.0Mpa |
|
Voltage/Power |
V/KW |
220V/1KW |
|
Weight |
Kg |
500 |
|
|
Pre-heater
|
Dimension |
mm |
1870*630*1450mm |
Weight |
kg |
260 |
|
Voltage/Power |
V/KW |
380V/14KW |
