water vendeMachine with coin and IC card for Drinking Water

Simple description:

Auto water vending machine produces pure drinking water, municipal tap water is filtered by activated carbon, PP sediment filter, reverse osmosis membrane. Then through mineralization treating, living ozone sterilizing, 24hours UV sterilizing. Sand, corrosion, heavy metal, bacteria, residual chlorine and their derivative, all kinds of organic pollutant are all removed completely, ensuring output water clean and make sure it is drinking water .

Features:

Operation Instruction:

Features:

1.The machine adopts advanced reverse osmosis (RO) filter purification technology, 6 steps filter, high effectively remove sand, heavy metal, organic compound, bacteria etc. harmful substance for human body.

2.Ultraviolet ray (UV)24 hours non-stop sterilizing, ensure water hygiene

3.Adopting high concentration ozone to disinfect water tank, completely eradicate water polluted secondarily.

4.Perfect and regular technique of drinking pure water production reflects on the machine, cabinet style decent design, technological process clear, easy for maintainance.

5.High quality ultra low pressure TFC compound RO membrane treatment technology, deion rate is above 99%. Equipped with perfect pre-treatment and post-treatment filters, can produce drinking pure water that accords with "pure water standard".

6. Multi medium pre-filter improves its filter ability, protects the following filter material , especial the RO membranes.

7.activated carbon filter can effectively absorb 100% residual chlorine, protect RO membranes from harm of residual chlorine, at the same time, remove the color and smell, improve taste of the pure water.

8. Before every pump inlet is assembled with water pressure protection control device, as long as connect electric power, open feed water valve, pressure of pump inlet exceeds adjusted water pressure, pump will auto start. If the water pressure of pump inlet is below adjusted value, pump will auto stop.

9. more safe and reliable electrical system design, added RO membranes auto rinsing, low water pressure protection and according to water level of the post water tank to make machine auto start and auto stop.

10. Coin and smart IC card charging technology, dual insurance, select the two kinds of charging mode, precision can reach 0.01.
