Home > Products > ZTE Ethernet Switches > ZTE ZXR10 1150-8T 1150-5T 1150-16T Unmanaged switch
ZTE ZXR10 1150-8T 1150-5T 1150-16T Unmanaged switch
- 10000 Set / Sets per Month
- Hongkong/Shenzhen
- Credit Card PayPal
- ZTE Switch ZXR10 2600 Series L2 Access Ethernet Switch RS-2600
- ZTE Switch ZXR10 5250 Series All Gigabit Intelligent Switch RS-5250-52PM-H
- ZTE Switch ZXR10 5250 Series All Gigabit Intelligent Switch RS-5250-28TC-H RS-5250-28TM-H RS-5250-52TM-H RS-5250-28PM-H
- ZTE Switch ZXR10 5250 Series All Gigabit Intelligent Switch RS-5250-28TC RS-5250-52TC RS-5250-28SM RS-5250-28PM RS-5250-52PM
- ZTE 5950-52TM, RS-5950-52TM-AC, 44 GE RJ45,4 GE Combo+4 expansion card ZTE ZXR10 5950
- ZTE RS-59EC-4GE-SFP/C, 4-port GE optical interface clock extension card ZTE ZXR10 5900E 5950-H 5960 5916E 5928E 5952E
Product Details
Products Status: | Stock | Ports: | Other, ≥ 48 | Transmission Rate: | 10/100/1000Mbps |
Function: | LACP, POE, QoS, SNMP, Stackable, VLAN Support | Communication Mode: | Other, Full-Duplex & Half-Duplex | Certification: | CE RoHS FCC |
Switch Capacity: | 32Gbps | Brand Name: | ZTE | Model Number: | ZTE ZXR10 1150-8T |
Place of Origin: | Guangdong, China |
Packaging Details
orginal packaging
Product Description
ZTE ZXR10 1150-8T 1150-5T 1150-16T Unmanaged switch
ZXR10 1000 Series Intelligent Switch
The ZXR10 1000 series intelligent Ethernet switches of ZTE are designed for access layers to enable fast deployment and convenient access. This series includes two types, i.e. unmanaged and WEB-managed ones. So these switches can be widely used in many scenarios, e.g. small and middle-sized enterprises, hotels and cybercafes, etc.
Totally there’re 8 models of ZXR10 1000 series unmanaged intelligent Ethernet switches:
1150-5T: 5FE RJ45
1150-8T: 8FE RJ45
1150-16T: 16FE RJ45
1150-24T: 24FE RJ45
1160-5T: 5GE RJ45
1160-8T: 8GE RJ45
1160-16T: 16GE RJ45
1160-24T: 24GE RJ45
There are 4 models of ZXR10 1000 series web-managed intelligent Ethernet switches:
1660-10TS: 8*GE RJ45+2*GE SFP
1660-16TC: 16*GE RJ45(2*GE combo)
1660-24TC: 24*GE RJ45( 4*GE combo)
1660-24PC:24*GE POE/POE+(4*GE combo)
ZXR10 1000 series unmanaged intelligent Ethernet switches
Specifications | 1150-5T | 1150-8T | 1150-16T | 1150-24T | 1160-5T | 1160-8T | 1160-16T | 1160-24T | |
The number of fixed ports | 5FE RJ45 | 8FE RJ45 | 16FE RJ45 | 24FE RJ45 | 5GE RJ45 | 8GE RJ45 | 16GE RJ45 | 24GE RJ45 | |
Basic parameters | Switching capacity | 1G bps | 1.6G bps | 3.2G bps | 4.8G bps | 10G bps | 16G bps | 32G bps | 48G bps |
Packet forwarding rate | 0.74 MPPS | 1.19 MPPS | 2.38 MPPS | 3.57 MPPS | 7.44 MPPS | 11.9 MPPS | 23.8 MPPS | 35.7 MPPS | |
MAC table capacity | 1k | 2k | 8K | 8K | 2k | 8K | 8K | 8K | |
Physical parameters | Size (W*D*H) | 98 mm *71 mm *29mm | 133 mm *72 mm *28mm | 294 mm *180 mm *44mm | 440 mm *180 mm *44 mm | 128 mm *96 mm *31mm | 172 mm *108 mm *32mm | 294 mm *180 mm *44 mm | 440 mm *180 mm *44 mm |
Weight | 0.17kg | 0.23 kg | 1.3 kg | 1.8 kg | 0.19 kg | 0.26 kg | 1.55 kg | 2.3 kg | |
AC power supply | 100V~240V,50Hz~60Hz (power adapter) | 100V~240V,50Hz~60Hz | 100V~240V,50Hz~60Hz(power adapter) | 100V~240V,50Hz~60Hz | |||||
Maximum power consumption | 1.5W | 1.5W | 1.48W | 2.63W | 3.3W | 5.6W | 8.2W | 10.3W | |
Long-term working environment | 0℃-40℃ (32℉~104℉), 10%~90% non-condensing | ||||||||
Storage environment | -40℃-70℃ (-40℉~158℉), 5%~90% non-condensing |
ZXR10 1000 series WEB-managed intelligent Ethernet switches
Specifications | 1660-10TS | 1660-16TC | 1660-24TC | 1660-24PC | |
The number of fixed ports | 8*GE RJ45+ 2*GE SFP | 16*GE RJ45(2*GE combo) | 24*GE RJ45(4*GE combo) | 24*GE POE/POE+(4*GE combo) | |
Basic parameters | Switching capacity | 20Gbps | 32Gbps | 48Gbps | 48Gbps |
Packet forwarding rate | 14.9Mpps | 23.8Mpps | 35.7Mpps | 35.7Mpps | |
MAC table size | 8K | ||||
Physical parameters | Size(W*D*H) | 294mm *180 mm *44mm | 440 mm *220 mm *44 mm | 440 mm *330 mm *44 mm | |
Weight | 1.45kg | 2.7kg | 3kg | 5.36kg | |
AC power supply | 100V~240V,50Hz~60Hz | ||||
Maximum power consumption | 10.7W | 14.7W | 23.3W | 401.3W (System power consumption81.3W,POEpower output320W) | |
Working environment | Working temperature:0℃~40℃ (32℉~104℉),humidity: 10%~90%non-condensing | ||||
Storage environment | Storagetemperature: -40℃~70℃ (-40℉~158℉);humidity: 5%~90%non-condensing |
