WATER Meter (LXH-15-40)

Specifications

Rotary pistion water meter
CLass C,
brass body,with a pair of connectors









Features:



Rotary piston system.long service life



Dry-dial or liquid sealed register,keeps clear reading for long time°c



High measuring accuracy,the starting flow of the meter is 2 L/Pulse or less



Can be installed in any position



Brass body,m³  or gal,optional



Remote transmisson can be added upon request



Many kinds of sensors,such as Reed Switch,Hall and Weagand can be supplied upon request;



Pulse output maybe 1L/Pulse



ISO 4064 :1993 Class C



ISO 4064:2005 R160/R200



Working condition:



Water temperature 50°c



Water pressure≤1MPa

(PN:1.6MPa/16bar)

ΔP≤0.1MPa(Class C/Class D)

ΔP≤0.063MPa(R160/R200)



Accuracy:



From minimum flow-rate(qmin/q1)inclusive, to transitional flow-rate(qt/q2),exclusive:±5%

From transitional flow-rate (qt/q2)inclusive,to overload flow-rate(qs/q4),exclusive::±2%



Technical Data:



DN/Q	Q4=1.25Q3       Q3	R=Q3/Q1	Q2=1.6Q1    Q1	R=Q3/Q1	Q2=1.6Q1     Q1
	l/h		l/h		l/h
20	5000                4000	160	40                 25	200	32                  20



Nominal size DN9mm)	Classof measurement	Overload flow-rate qs	Permanent flow-rate qt	Transitional flow-rate qt	Minimum flow-rate qmin	Minimum reading Min	Maximum reading Max
20	C	5	2.5	37.5	25	0.0001	9999



Overall dimensions and weight:

Type	Size(mm)	Length(mm)L	Width(mm)W	Height(mm)H	Connecting Thread D	Weight (kg)
LXH-20	20	270	165	90	G1"B	1.8
