4STC--1325HN High Accuracy CNC Machine Tools
Advantage:
1. High quality
2. Imported guild rail
3. High stability and precision
4. CE, ISO certificate
Detailed Product Description:
1. The lathe bed is wholly cast with iron, it can assure high stability and not easy to deformation, it can process the material on the table randomly.
2. Adopt the imported guide rail, ball bearing piece, can bear high weight, run stability, high precision, long life.
3. Intelligent protection for working table can avoid the damaging the table own to wrong operation or software fault. Its protection of step beyond the boundary avoids the crash while design area beyond processing area.
4. Advanced DSP controller can control automatically the muti-layer 3D processing with high speed. It also can be opera offline.
5. The compatibility of the software is good, it can compatible type3/Artcam/Castmate/Artcut and CAD/CAM design software.
Applicable industry
1. Widely used in furniture processing, home decoration, woodworking decoration, wooden arts and crafts, stone carving processing etc. industries.
Technical Parameters:
| Model No | 3STC-1325H Wood CNC router | |
| Machine Size (mm) | 1380mm* 2900* 200mm | |
| Engraving range (mm) | 1300mm* 2500* 200mm Professional wood cnc router manufacturer 3STC-1325H | |
| Structure options | Casting Iron struture | |
| X Axis travelling range | 2500mm | |
| Y Axis travelling range | 1300mm | |
| Z Axis travelling range | 200mm | |
| Spindle power (KW) | 3KW optional | |
Guide rail |
Taiwan Hiwin linear guide Square rail | |
Working voltage |
380v50HZ±10 | |
Software |
Type3 Software/France |
|
Command |
G Code,U00,mmg,nc | |
| Positioning accuracy | ±0.15/300 | |
| Repositioning accuracy | 0.003 | |
| Step resolution | 0.00625/pluse, optional | |
| Diameter of cutting tools (mm) | 3.175/ 4.0/ 6.0/ 8.0/ 12mm optional |
|
| Control system option | Wei Hong Motion Control System of Shanghai, optional | |
| Cooling system | Water,optional | |
| Gross weight | 1100KG | |
Samples:
Shipping Terms
1,EXW
2,FOB SZ
3,CIF+Destination port
4,If you need us to book shipping cargo or not and etc,pls notice us,we are more pleased to do so.
Payment terms
1,T/T 30%T/T in advance against the order confirmed and pay the balance 70% against goods ready.
2,Western Union Total amount should be below than 5000 USD,and the bank handling fee should be responsible for you.
3,L/C We would like to talk details with you if you really need L/C payment terms.
Why choose us?
1.One year equipment warranty and maintenance for lifetime.
2.Free installation and test before shipping and free training for operators
3.Advice for the solutions best for customers requirements.
4.Free training and sample provided
5.Meet CE,FDA,ISO9001 standards
