CNC Woodworking Machinery With low noise ( 12STC-2022)
Application Materials
Foam, Styrofoam, EPS Foam, Wood, MDF, Solid wood, Hardwood, Artificial stone, Marble, Granite, Ceramic Tile, Tombstone, milestone, Terrazzo, Limestone, Sandstone, Travertine, Quartzite, Slate, grindstone ,Jade, crystal, plexiglass, aluminum composite panel, aluminum block, copper and so on.
Samples
Specification:
Model No |
12Stc-2022 |
Table Size |
2400mm×2600mm |
Effective Engraving Size |
2000mm×2200mm D500*2200 |
Z Axis Travelling |
750mm |
Feeding Height |
900mm |
Body Frame/Structure |
T-Steel(Steel structure 8mm Steel Pine) |
Table Material |
Thickness Aluminum |
Portal Side Wall Configuration |
Cast Iron |
Z Axis Movement Hardware Configuration |
Cast Aluminum |
Transmission Configuration |
Rack Gear(Germany Slanting Rack) |
Rail Configuration |
25mm Ball screw |
Z Axis Screw |
25 mm Screw C4 Grade,Double nut |
Positioning Accuracy |
±0.15/300mm |
Spindle Rotating Speed |
0-24000(rmp/min) |
Processing Speed |
0-30000mm/min |
X Axis Motor Drive |
France Schneider Servo Motor |
Y Axis Motor Drive |
France Schneider Servo Motor |
Z Axis Motor Drive |
France Schneider Servo Motor |
Movement Control |
NCstudio Control System |
Carving Instruction |
G Code*,U00*,mmg*,nc |
Resolution |
0.0025/Pulse |
Collet |
3.175mm,4mm,6mm,8mm, 12.7mm |
Spindle Rotating Power |
3.0KW Bearing Water Cooling Motor(4 pcs) |
Conventor |
Best,Independent conventor 4pcs |
Power |
220V/380v50HZ±10(Internal Switch Power) |
Weight |
Appro42000KGS |
Electric Box Configuration |
Computer capinet |
Movement Method |
Gantry Moving |
Shipping Terms
1,EXW
2,FOB SZ
3,CIF+Destination port
4,If you need us to book shipping cargo or not and etc,pls notice us,we are more pleased to do so.
Why choose us
1.One year equipment warranty and maintenance for lifetime.
2.Free installation and test before shipping and free training for operators
3.Advice for the solutions best for customers requirements.
4.Free training and sample provided
5.Meet CE,FDA,ISO9001 standards
