Electronic Ballast For Fluorescent Lamp T8 4x18W 2x36W
- 2000 Piece / Pieces per Month
- NINGBO
- T/T
Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | RISESUN | Model Number: | P118B |
| Style: | Electronic | Usage: | High Intensity Discharge | Matched Tube: | T8 |
| Power Factor Compensation: | Active |
Product Description
Model | P118B | Power rising | 3min |
Size | 212x29x30mm | Input voltage | 90-280V |
Mogul attachable style | available | Operation frequency | 50Hz-60Hz |
Colorful | Available | input Power | 10-62W |
Dimmable | 4dimming 110%100%75%50% | Output Power | 10-60W |
THD | 5% | input current | 0.10-0.56A |
Efficiency up to | >94.7% | Input frequency | 50Hz~60Hz |
Power factor | >0.95 | Output short protection | available |
Lgnite peak voltage | 220V | Open circuit protection | available |
Enclosure temperature | -15°C-55°C | Ignition failure protection | available |
Life:30000h
Use IC oscillating circuit, frequency conversion preheat Start, tube voltage is the sine wave, effectively prolong lamp life, and high stability.
Protection against no tubes, and input wrong wiring, Good regulation against supply voltage variation,
protection against low and high voltage.
Energy-saving up to 30% compared with magnetic ballast.
widely use for train, car, ship lighting, sauna lighting, Move lighting, solar lighting, and so on. Satisfy different requirements of lighting voltage .
TUV/CE /EMC/CCC are available
| Model No. | Power | Product Size | Model No. | Power | Product Size |
| BL-01 | 8 | 37*167 | P218B | 2*18 | 28*28*200 |
| BL-02 | 8 | 42*78 | P158B | 58 | 28*28*200 |
| BL-03 | 6 | 42*78 | P236B | 2*36 | 28*38*210 |
| BL-04 | 12 | 92*47*29 | P258B | 2*58 | 30*35*280 |
| BL-05 | 12 | 150*42*26 | P236H IC | 72 | 150*40*29 |
| BL-07 | 8 | 150*40*29 | WO-236 IC | 2*36 | 29*40*150 |
| P118A | 18 | 27.5*28*274 | WO-258 IC | 2*58 | 28*38*210 |
| P136A | 36 | 27.5*28*274 | EU118B | 1*18 | 274*27*27 |
| P218A | 2*18 | 27.5*28*274 | EU136B | 1*36 | 274*27*27 |
| P158A | 58 | 27.5*28*274 | EU158B | 1*58 | 274*27*27 |
| P236A | 2*36 | 30*35*280 | EU218B | 2*18 | 274*27*27 |
| P118B | 18 | 28*28*200 | EU236B | 2*36 | 274*27*27 |
| P136B | 36 | 28*28*200 | EU258B | 2*58 | 280*34*30 |
