Help CenterCCA Welding Wire
Related Products
Specifications
1. Choice conductor material for Computer2. Mobile communications wire
3. Coil or column used in Aeronautics and Astrona
|
Copper clad aluminum is a composite wire consisting of an aluminum core clad with copper.Even though the material is 65 - 75% aluminum, the wire has high frequency electrical properties equal to solid copper. The advanced coated welding manufacturing technology integrate the cooper cover and the aluminum pole to a whole and then pull out and annealing processing could be used. Advantages: 1.DC Resistivity: The resistivity rate of CCA 1.5 times than Copper Line 2.Good corrosion resistance 3.Light weight and low cost 4.Good weldability |
High conductivity |
|
Copper clad aluminum is a composite wire consisting of an aluminum core clad with copper.Even though the material is 65 - 75% aluminum, the wire has high frequency electrical properties equal to solid copper. The advanced coated welding manufacturing technology integrate the cooper cover and the aluminum pole to a whole and then pull out and annealing processing could be uesd SpecificationsCopper strip clad aluminum wire Copper Clad Aluminum (CCA) Wire Copper clad aluminum is a composite wire consisting of an aluminum core clad with Parameters:
1) Diameter: 0.15 - 3.00mm 3) It is divided into 25% and 8% two kinds according to volume scale of copper layer 4) The DC resistivity at temperature of 20°C is less than 0.02676Ω.mm²/m 5) Its nominal density is 3.32g/cm³ - 3.63g/cm³, it is 35 - 37% of pure copper wire 6) Under the same weight, its length is 2.5 - 2.7 times that of pure copper wire 7) It has become the most common wire used in CATV and other high-frequency conduct cable 8) It is a bimetallic wire with a copper cladding concentrically covering an aluminum core, integrating the beneficial properties of the wonderful conductivity of copper and the light-weight of aluminum. 9) It can be scientifically processed into bare wire , and it is the best material for coaxial cable, computer cable, telephone cable and shielding cable. 10) The processing method is similar to that of copper wire during cable manufacture. |
Send Inquiry to This Supplier
