CY6250B/CY6266B SERIES

CY6250B/CY6266B SERIES thumbnail-1
CY6250B/CY6266B SERIES photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Turning Center
CNC or Not:
Normal
Contact Supplier Request Quote Chat Now
Shaanxi Yuan Hang Machinery Equipment Import & Export Corp., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Turning Center
CNC or Not Normal
Place of Origin Shaanxi, China
Brand Name Yuanhang
Model Number CY6250B/CY6266B SERIES

Specifications

1.CE,standard
2.No.1 quality in the market
3.High quality to price ratio
4.spare parts suppor

1. High rigidity spindle system, with absolute temperature rising no higher than 35 .
2. Reliable safety devices such as footbrake and emergency power-off switch are assembled. Adjustable overload protection device is also installed in the feed system.
3. Rapid feed system to improve efficiency. Wide range of feed and pitch are available without changing gears.
4. The bed way is made of high-quality cast-iron and induction-hardened. Hardness is around HRC 55.
5. Tailstock are equipped with double-locked mechanism, smooth and effortless movement is realized through the underneath elastic scroll devices.
Model
Specification
CY6250B
CY6266B
Swing over beb
500mm
660mm
Swing over cross slide
300mm
380mm
Swing in gap
710mm
830mm
Width of gap
240mm
Width of beb
390mm
Length of work piece (max)
750,1000,2000,3000mm
Spindle nose
D8
Taper of spindle center
1:20
Spindle bore diameter
82mm
Spindle speed
9-1600rpm
Max. output torque of spindle
1470N.m
Range of longitudinal feed
0.028-6.43mm/rev
Range of transverse feed
0.12-2.73mm/rev
Lead screw pitch
12mm(metric system) 2TPI (inch system)
Lead screw diameter
40mm
Metric threads
1-224mm (48 pitches)
Inch threads
72-1/8TPI (48 pitches)
Module threads
0.5-112mm (42 pitches)
Diameter pitch threads
56-1/4DP (45 pitches)
Cross slide travel (max.)
320mm
350mm
Top slide travel (max)
145mm
170mm
Longitudinal rapid traveling speed
4.5m/min (50HZ)
Transversal rapid traveling speed
1.9m/min (50HZ)
Sleeve diameter
75mm
Morse taper of sleeve
M5
Max. traveling of sleeve
150mm
Main drive motor
7.5kw,11kw (optional)
Rapid travel motor
250w
Coolant pump motor
90w
Standard Accessories:
1. 250mm 3-jaw chuck,
2. 400mm 4-jaw chuck,
3. 630mm face plate,
4. 250mm Drive Plate,
5. 20130mm Steady Rest,
6. 20-80mm Follow Rest,
7. Thread Chasing Dial,
8. 5# Live Center,
9. Center,
10. Center Sleeve,
11. Chip Guard,
12. Coolant System,
13. Illuminating System,
14. Foot Brake,
15. Operation Manual,
16. Full Set of Wrench and Screw Driver, Foundation Bolts.
Optional Accessories:
1. Taper Turning attachment (TTA),
2. Micro Stop for Saddle,
3. 4-Position Stop for Saddle,
4. 4-Position for Cross Slide,
5. Quick Change Tool Post,
6. Halogen Work Lamp,
7. Damping Washer,
8. Digital Readout (DRO),
9. CE Standard Compliance.
