Home > Products > Sifter series > Durable Vibrating Screener
Durable Vibrating Screener
- Shanghai China
- T/T L/C D/P D/A Money Gram Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Air Separation Plant | |
| Product Type | Detergent Powder | Place of Origin | Jiangsu, China | |
| Brand Name | Xinanfenti | Model Number | ZS-350 | |
| Voltage | 380V | Power(W) | 550W | |
| Weight | 100kg | Dimension(L*W*H) | 540*540*1060 | |
| Certification | ISO9001,and accord with GMP standard | Warranty | One year warranty , for life maintenance | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
It is suitable for filtering on assemble line in the industry of pharmaceuticals,chemical,foodstuff and ect.Main Application
The machine is suitable for flow operation, and is the ideal equipment for sifting out the granules in different sizes and proportion and for continuous material Delivering.
Structure and Characteristics
The machine is composed of the hopper, vibration chamber, clutch, motor, etc. The vibration chamber is equipped with eccentric wheel, rubber soft pieces, main
Shift, bearings, etc. When the adjustable eccentric weight passed its gravity to the central line of main shift by the driving of motor to break the balance, then
Under the centrifugal force, the orbit spire of target material is forced to change its way in the chamber. The size of swing of the weight regulator van be adjusted
According to different kinds of target material or the number of mesh. The whole machine has the specialties of compact structure, small volume, nondust flying, low
Noise and high output, low energy consumption, easy to be moved and maintained.
Technical Data
Model | Model350 | Model 515 | Model650 |
Capacity(kg/h) | 60-500 | 60-1300 | 180-2000 |
Number of mesh | 12-200 | 12-200 | 12-200 |
Motor power(kw) | 0.55 | 0.75 | 1.50 |
Speed of principal axis (r/min) | 1380 | 1370 | 1370 |
Weight (kg) | 100 | 180 | 250 |
Overall size (L×W×H)(mm) | 540×540 ×1060 | 710×710 ×1290 | 880×880 ×1350 |
