China Latest Lifting machinery feed machinery
- 60 Set / Sets per Month
- Shanghai China
- T/T L/C D/P D/A Credit Card PayPal
- seamless softgel capsule machine for the beads and aroma mini ball production
- Latest AI Algorithm High Efficiency Visual Inspection Machine Equipment for Glass and PET Plastic Bottles Preforms
- Advanced High Efficiency AI Visual Quality Analyzer for Grains and Nuts Classification Grading machine
- Factory Price High Efficiency AI Visual Inspection Machine for Caps Defects Detection
- High Precision Automatic AI Vision Defect Inspection Machine for Plastic PET PP PE Bottles
- Automatic High Speed AI Visual Inspection Machine for Defects Food and Beverage Package
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Xinanfenti | Model Number: | YTG |
Application: | Powder | Type: | Filling Equipment | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
YTG series mobile lifting feeder is used to convey,lift and feed solid material,such as powder ,granuies and ect.Specifications
1. YTG Series Mobile Lifting Feeder Machine
2.Model:YTG
3.Charginfg dropping height:less than 1800
YTG Series Mobile Lifting Feeder
Main Application:
The mobile retractable lifting feeder of YTG series is used to convey,lift and feed solid material,such as powder,granules and etc.In the pharmaceutical industry,it can equip with mixer,pelletizer,tablet machine,sugar coating machine and capsule filler for transferring material to nest process.So it optimizes the process of granule manufacturing and efficiently reduces dust and cross pollution.This ideal conveying machine achieves the standard of GMP.
Operating Principle:
This machine consists mobile underpan, pole,hydraulic lift system and turning hopper.When it works,cone and hopper interlocks to trigger hydraulic lift system.Cone container can turn over 180°.Mobile underpan can be docking with the material entrance in the next process.The height from the ground to the discharge hole is 1.8m and the height of the machine is 1.95m.It is easy to move in the factory and widely used in different workshop.
Feature:
The machine is made of stainless steel,there is no dead convene and concave surface,or screw in the exposed part.So it is convenient to clean.
The hopper has adopted sealing system and there is no dust or leakage when the bucket turns down,so the dust and cross pollution are efficiently controlled.
It is designed with the oil storage tank to prevent the hydraulic oil from polluting the clean area.
The machine is newly developed type with lots of researches and references from overseas advances machines and design.The structure is compact,the performance is reliable and stable,the appearance is pleasing and it is easy to clean.The main machine technical parameters correspond to that of the similar machine tye of international market in the 19 century.It has filled the vacancy of domestic market and is completely conforming to the GMP standard of pharmaceutical production.
Nowadays, Jiangyin Xinan Machinery Co.,ltd have customers both in China and abroad.Foreign customers such as Russian,East Europe,Middle East,South America,North America,East Asia,Southeast Asia, Africa,etc.
Model | YTG50 | YTG100 |
Maximum load(kg) | 50 | 100 |
Power(kw) | 0.75 | 1.5 |
Total weight(kg) | 300 | 400 |
Charge dropping height(mm) | less than 1800 | less than 1800 |
Overall size(mm) | 1700×650×1950 | 2050×750×1950 |
