UNIVERSAL KU-BAND SINGLE LNB

UNIVERSAL KU-BAND SINGLE LNB thumbnail-1
UNIVERSAL KU-BAND SINGLE LNB photo-1
US$ 1.2 - 1.6 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
JPARK
Model Number:
SR 11C
Contact Supplier Request Quote Chat Now
Guangzhou Jpark Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name JPARK
Model Number SR 11C
FTA(Free To Air) Yes
Type Digital
High Definition Yes

Specifications

1 waterproof
2 low noisy
3 high gain quality&competitive price
4 1 year warrantly

RF INPUT

Frequency Range

Low Band:10.70-11.70GHz

Hige Band:11.70-12.75GHz



IF OUTPUT

Frequency Range

Low Band: 950-1950MHz

Hige Band:1100-2150MHz

Connector Type

75Ω

VSWR

2.0:1(Typ)





Local Oscillator

Frequency

Low Band: 9.75GHz

Hige Band: 10.60GHz

Frequency Stability

±1.5MHz

Frequency Phase Noise

-55dBc/Hz@1KHz

-80dBc/Hz@10KHz

-100dBc/Hz@100KHz

Noise Figure



0.7dB(Typ)



Conversion Performance

@Roon Temperature

Conversion GAIN

65dB

Gain variation (P-P)

5dB(Typ)

Gain Flatness

±0.5dB(Typ)/26MHz

Image Rejection

45dB





Power Requirements

DC Current Consumption

200mA(max)

Operating Voltage

Vertical:11.5-14Vdc

Horizontal:16-19Vdc

Band Switching

Low Band: 0Hz

Hige Band: 22KHz±4KHz

Environment

Operating Temperature

-40°C~+60°C

Storage Temperature

-55°C~+80°C

OUTPUT IMPEDANCE

75 OHMS

IF OUTPUT CONNECTER
