Specifications
1.agricultural products dryer.2.Model:SZG
3.Pressure in tank:-0.01-0.15
4.Jack design pressure:
agricultural products dryer
Main Application:
SZG Series twin cone-shaped Rotary Vacuum Dryer is used in the industry of pharmaceutical,foodstuff,feedstuff,and chemical to dry material,such as tablet,instant soluble medicine,instant soluble food,plastic,resin and eatable powder.
Feature:
Target material can be heat sensible,easily oxidized,fragile crystal,recycled soluble granules and poisoning material.
When the container rotates,heating point is continuously changes,so material dries rapidly and evenly.Indirect heating can prevent pollution and dead corner.It is easy to clean maintain and operate.The design ensures well sealed function.
Operating Principle:
Well sealed interlayer is designed for heat carriers,such as water and vapour.Heat is delivered to material through inner side.The container rotates slowly and material gets mixed and heated.Steam from the material releases in a vacuum room and pumps out to recycle so that material gets dry rapidly.
Main Market:
North America
South America
Eastern Europe
Southeast Asia
Africa
Oceania
Mid East
Eastern Asia
Western Europe
Central America
Northern Europe
Southern Europe
Domestic Market
Model |
100 |
350 |
500 |
750 |
1000 |
1500 |
2000 |
3500 |
4500 |
Tank volume(L) |
100 |
350 |
500 |
750 |
1000 |
1500 |
2000 |
3500 |
4500 |
Loading volume(L) |
less 50 |
less 175 |
less 250 |
less 375 |
less 500 |
less 750 |
less 1000 |
less 1750 |
less 2250 |
Rotating speed(rpm) |
3-13 |
||||||||
Motor power(kw) |
0.75 |
1.1 |
1.5 |
2100-2400 |
3 |
3 |
4 |
5.5 |
7.5 |
Floor space(mm) |
2160×800 |
2260×800 |
2150×800 |
2560×1000 |
2860×1300 |
3260×1400 |
3760×1800 |
3760×1800 |
3960×2000 |
Rotary height(mm) |
1750 |
2100 |
2250 |
2490 |
2800 |
2940 |
2990 |
3490 |
4100 |
Design pressure inside tank (MPa) |
-0.01-0.15 |
||||||||
Jacket design pressure(MPa) |
less than0.3 |
||||||||
Working temperature(°C) |
In tank less than |
Jacket less than 140 |
|||||||
Condensing vacuum pump |
2X-15A |
2X-30A |
2X-30A |
2X-30A |
2X-70A |
JZJX300 |
JZJX300 |
JZJX600 |
JZJX600 |
Vacuum, power |
2KW |
3KW |
3KW |
3KW |
5.5KW |
87KW |
49.5KW |
811KW |
420.5KW |
No Condensing Vacuum |
SK-0.4 |
SK-0.8 |
SK-0.8 |
SK-2.7B |
SK-2.7B |
SK-3 |
SK-6 |
SK-6 |
SK-6 |
Pump models, power |
1.5KW |
2.2KW |
2.2KW |
4KW |
4KW |
5.5KW |
11KW |
11KW |
11KW |
Weight(kg) |
800 |
1200 |
1200 |
1500 |
2800 |
3300 |
3600 |
6400 |
7500 |
