Product Details
Place of Origin: | Henan, China | Brand Name: | YUTONG | Model Number: | YTZ5310JQJ1 |
After-sales Service Provided: | Overseas service center available |
Product Description
Yutong bridge inspecting vehicle YTZ5310JQJ1
The trusswork of bridge inspection platform is made of high-strength rectangular tube imported from Germany. The complete set of software and hardware of electrical control system adopt products imported from Italy 3B6 Company.
Parameters of vehicle inspection equipment
Horizontal operating range under the bridge (mm) | 10325~18000 |
Working platform's maximum dimension of getting off the bridge (mm) | 8000 |
Rated load/remote load of working platform (kg) | 600/300 |
Swing angle of working platform under the bridge (°) | 180 |
Distance of crossing the sidewalk (mm) | 2100~2500 |
Height of crossing the guardrail (mm) | 2200 |
Structural type of working platform | Trussed type |
Main power of working device | Take the force from chassis through power take-off |
Standby power of working device | Gasoline engine unit |
Drive type of self-propelled device | Hydraulic drive |
Self-propelled speed (m/min) | ≤16 |
Operation method | Manual, electric control |
Communication mode | Wired and wireless intercom system |
Monitoring mode | Wired monitoring system |
Working size of Bridge-inspection Vehicle
As a specialized supplier of construction machinery of PLA Construction Engineering Corps, Yutong Heavy Industries has made outstanding contributions to the national defense construction, supplied thousands of various equipment like high-speed bulldozers and loaders for this Corps, and been highly appraised by the army due to the high quality of its products in the past 60 years.
Manufacturing
Yutong Heavy Industries has more than 60 kinds of products that can be classified to such 5 categories as shoveling and transporting machinery, environmental protection equipment and environmental protection engineering, piling machinery, special purpose vehicle, construction hoisting machinery, with its business covering the roads, railways, hydraulic engineering, architectural engineering, coal mines, petroleum engineering, civil engineering, environmental protection.
R&D Center
Located in Zhengzhou City, Henan Province and occupying a land of four hundred sixty-five thousand square meters, the company has about 3500 employees including more than 470 construction technicians. It has its own academician working station and provincial corporate technical center so it has a powerful technical innovation and new product development ability.
Welcome to consult us any question you have !
