Two Axles Road Wrecker Towing Truck

Name: Two Axles Road Wrecker Towing Truck
Brand: YUTONG
SKU: 119097713

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Fuel Type:

Diesel

Condition:

New

Dimensions (L x W x H) (mm):

8810*2500*3290

Zhengzhou Yutong Heavy Industries Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai&Tianjin&Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Fuel Type Diesel

Condition New

Dimensions (L x W x H) (mm) 8810*2500*3290

Place of Origin Henan, China

Brand Name YUTONG

Model Number YTZ5197TQZ40EN

Two Axles road wrecker towing truck

Product Description

Picture of Road-block removal truck

Major technical parameters of YTZ5197TQZ40EN

Overall dimension of complete vehicle (mm)	8810×2500×3290
Wheelbase (mm)	5600
Wheel track of front wheel (mm)	2022
Wheel track of rear wheel (mm)	1830
Maximum under-pulling capacity (kg)	19000
Maximum hoisting-pulling capacity (kg)	12000
Furthest hoisting-pulling capacity (kg)	5800
Telescopic stroke of boom (mm)	2500
Maximum hoisting height (mm)	5500
Maximum lift angle (°)	35
Rated tractive force of winch (kN)	80
Number of winch	2
Maximum under-hoisting capacity (kg)	6400
Maximum under-hoisting capacity in full-extension condition (kg)	5000
Maximum efficient under-hoisting length (mm)	3900
Telescopic stroke of support arm (mm)	925×2
Folding angle of support arm (°)	-7~+92°
Kerb mass of entire vehicle (Kg)	14500
Maximum vehicle speed (km/h)	90
Maximum gradeability (%)	≥20
Maximum turning diameter (m)	≤23
Minimum ground clearance (m)	≥260
Approach angle (°)	16
Departure angle (°)	15

Main configurations of YTZ5197TQZ40EN

Chassis model	ZZ1167N5618W
Engine model	WD615.95C
Rated power of engine (kw/hp)	249/340
Rated speed of engine (rpm)	1900
Maximum torque (N.m)	1490(1200~1500rpm)
Engine type	Compression-ignition type, high-pressure common-rail, in-line 6-cylinder, supercharged inter-cooled diesel engine
Clutch	Single-sheet dry type, pull-type diaphragm clutch φ430
Transmission	HW15710
Front axle (t)	HF7
Middle and rear axles (t)	STR
Front suspension	Non-independent leaf spring
Rear suspension	Non-independent leaf spring
Cab	HW76 flat-roofed and extended cab, equipped with single sleeping berth
Tyre	12.00-20
Service brake	Dual-circuit air brake, equipped with load sensing proportional valve to adjust the braking force
Parking brake	Air brake braking by spring energy storage chamber
Auxiliary braking	Engine exhaust brake
