20T waste transfer truck
Performance characteristics of YTZ5250ZXX40E
(1) HOWO ZZ3257M4647C1 chassis produced by China National Heavy Duty Truck Group, double reduction and 13 ton rear axle provide excellent overloading performance and good climbing ability;
(2) The upper part of hooklift adopts international famous brand, with light weight;
(3) Hydraulic components are imported, with long service life;
(4) Structural components of the hooklift are made of high-strength steel and welded by using automation equipment, providing good weld quality and reliable structures.
(5) Electric-hydraulic interlocking control provides high security;
(6) Hydraulic control system can control the speed of lowering the dustbin, so as to minimize the impact of lowering the dustbin on the beam of the vehicle;
(7) Electric-pneumatic-liquid joint control, which is operated within the cab and also can be operated in an emergency outside the cab;
(8) The support devices of rear wheels are welded by high strength steel, which can prevent the vehicle head from rising up when loading garbage.
Major technical parameters of YTZ5250ZXX40E
Overall dimension (mm) |
8550X2496X3225 |
Max. total mass (kg) |
25000 |
Rated load (Kg) |
12570 |
Wheelbase mm |
4625+1350 |
Engine power (kW/r/min) |
196/2200 |
Maximum vehicle speed (km/h) |
75 |
Approach angle/ departure angle(°) |
19/27 |
Maximum turning diameter (m) |
23.6 |
Maximum hoisting capacity of upper part of hooklift (t) |
20 |
Leading-in width of dustbin (mm) |
1070/910 |
Loading time (s) |
< 60 |
Lifting time (s) |
< 60 |
Maximum lift angle (°) |
48 |
Height of hook center (mm) |
1570 |
Main configurations of YTZ5250ZXX40E
Component Name |
Model |
Manufacturer |
Chassis model |
ZZ3257M4647C1 |
CNHTC Jinan Truck Co.,Ltd. |
Emissions standard |
National Ⅲ |
|
Engine |
WD615.92E |
China National Heavy Duty Truck Group Co., Ltd. |
Transmission |
HW14710 |
China National Heavy Duty Truck Group Co., Ltd. |
Front axle |
HF9 |
CNHTC Jinan Axle and Transmission Co.,Ltd. |
Rear axle |
ST16 |
CNHTC Jinan Axle and Transmission Co.,Ltd. |
Tire model |
12.00-20 |
|
Hooklift mounting model |
LBH2055 |
Shanghai Vehicle Loading Equipment Co., Ltd |
Manufacturing
Yutong Heavy Industries has more than 60 kinds of products that can be classified to such 5 categories as shoveling and transporting machinery, environmental protection equipment and environmental protection engineering, piling machinery, special purpose vehicle, construction hoisting machinery, with its business covering the roads, railways, hydraulic engineering, architectural engineering, coal mines, petroleum engineering, civil engineering, environmental protection.
R&D Center
Located in Zhengzhou City, Henan Province and occupying a land of four hundred sixty-five thousand square meters, the company has about 3500 employees including more than 470 construction technicians. It has its own academician working station and provincial corporate technical center so it has a powerful technical innovation and new product development ability.
Welcome to consult us any question you have !
