YUTONG YTPY180C Motor grader
MODEL |
|
YTPY180C |
Operating mass |
kg |
16000 |
Front axle load |
kg |
5150 |
Rear axle load |
kg |
10850 |
Max. forward speed |
km/h |
38.2 |
Max. backward speed |
km/h |
24.5 |
Speed gear number |
|
F6/R3 |
Turning radius |
mm |
7800 |
Hydraulic system pressure |
Mpa |
18 |
Blade length × height |
mm |
3965×610 |
Front wheel track |
mm |
2150 |
Rear wheel track |
mm |
2340 |
Wheel base |
mm |
6362 |
Engine model |
|
6BTA5.9 |
Engine power |
KW |
132 |
Overall dimensions |
mm |
8585*2790*3340 |
Engine |
|
Cummins engine |
Cab |
|
Cabin with AC. |
Packing |
|
Nude Cargo |
|
Main Features
1. Famous brand diesel engines turbocharged and water-cooled with reliable and powerful performance feature energy.
2. Torque converter and power-shift gearbox introduced from GERMANY ZF inc. are integrated together. Six forward gears and three backward gears meet various requirements during machine’s working and transporting.
3. Driving axle with integrated free-wheel anti-slip differential and strong roller chain drive tandem case, Boxed oscillated steering front axle with leaned wheels.
4. Popular working mechanism with pendulum-arm connecting rod structure, Standard equipped free-maintenance rolling-plate circle device. Double cylinders of the blade tip control can adjust the cutting angle depending on soil quality.
5. Flexible hydraulic control system with two sets of HUSCO five way control valve, Imported hydraulic equalizing valve for the blade lifting, Patent hydraulically –operated pin drawing device is designed firstly in board.
6. Steering system with center articulate joint and tilting turning front wheels can get offset travel of the entire machine.
7. Service braking system of, caliper disc brakes on four rear wheels and mechanical internal expanding parking brake let.
8. Dual diagonal appearance with whole metal hood 1m×1m distance.
9. Electro-hydraulically operated with entire instrumental monitoring system, Free
-maintenance OPTIMA Sweden batteries have.
10. It is optional for front bulldozing plate and rear ripper.
Manufacturing
Yutong Heavy Industries has more than 60 kinds of products that can be classified to such 5 categories as shoveling and transporting machinery, environmental protection equipment and environmental protection engineering, piling machinery, special purpose vehicle, construction hoisting machinery, with its business covering the roads, railways, hydraulic engineering, architectural engineering, coal mines, petroleum engineering, civil engineering, environmental protection.
R&D Center
Located in Zhengzhou City, Henan Province and occupying a land of four hundred sixty-five thousand square meters, the company has about 3500 employees including more than 470 construction technicians. It has its own academician working station and provincial corporate technical center so it has a powerful technical innovation and new product development ability.
Welcome to consult us any question you have !
- We supply the package of service to minning works. such as drilling, stone crushing, granule delivery, etc.
- We supply the package of service to sanitation works, such as road cleaning, city garbage compactor, delivery, etc.
- We supply the technique support to these customer for better usage of our products.
- 24 hours response principle, let us to help you faster and better.
- Some products can be found below, (Click the name or the picture for quick browsing)
-
Catalogue Products Description Dump truck Loadage can be 40t -100t Wheel loader Loadage can be 3t - 8 t Bulldozer 3 m3 capcity and other capcity Truck mounted crane 5t - 50 t Crawler crane 50t - 360 t Drilling rigs Rotary Drilling Rigs; Auger Rigs; Anchor rigs Sanitation equipment Sweeper; garbage compressing machine; sewage suction truck; Sprinkler Vehicle etc. Concrete Mixer Truck 8 m3 - 10 m3
You can contact with me for more information and serive.
- Can you give us a brief introduction to Yutong Company please?
We are military equipment supplier, our original facotry is founded at 1958. Good quality and competitive price is our advantage.
- How about the quality guarantee and after -sale service?
For quality guarate, we give one year guarantee, and with 24hours response principle for better service.
We have more than 30 agency all over the world, you can get the most convenient service by nearest agency.
- How about the payment terms?
We accept T/T, L/C, D/P, D/A,even L/G.
There is no packing to the main machine, small parts and wear parts will be packed in box . |
We usually use roll-on-roll-off ship because the volume is too big to be put into a container. |
|
