Product Description
MirocTapered equipment affords drillers the ability to change drilling bits whilst still using the same drilling rod. Drillers choose tapered button bits for faster drilling penetration rate. Different taper sizes have different characteristics when it comes to the “knock-off” index – the smaller angle will prevent the bit from spinning.
11°Tungsten Carbide Cross Bits Tapered Button Bit For Small Hole Range
• Suitable for small hole range
• Widely used in Dimensional Stone Quarrying Industry
• Widely used in Underground Mining Industry
Color: Green,Blue or Based on Customer requirements
Material: Tungsten carbide and high strength alloy steel
Processing: CNC milling and proprietary heat treatment process
Type: 11° carbide cross bit
Product Technical Reference
| Part Number |
Product Code and Brief Description |
Bit Diameter (mm) |
Bit Diameter (inch) |
Tip Size (W x H, mm) |
Front Flushing Holes |
Side Flushing Holes |
Weight (kg) |
| 4148300233 |
CR29-11D-22, 11° aper Cross Type Bit |
29 | 1 1/7 | 12 x 8 | 1 | 2 | 0.25 |
| 4148300234 |
CR30-11D-22, 11° Taper Cross Type Bit |
30 | 1 1/6 | 12 x 8 | 1 | 2 | 0.26 |
| 4148300235 |
CR32-11D-22, 11° Taper Cross Type Bit |
32 | 1 1/4 | 12 x 8 | 1 | 2 | 0.3 |
| 4148300236 |
CR33-11D-22, 11° Taper Cross Type Bit |
33 | 1 2/7 | 12 x 8 | 1 | 2 | 0.32 |
| 4148300237 |
CR35-11D-22, 11° Taper Cross Type Bit |
35 | 1 3/8 | 12 x 8 | 1 | 2 | 0.36 |
| 4148300238 |
CR36-11D-22, 11° Taper Cross Type Bit |
36 | 1 3/7 | 12 x 8 | 1 | 2 | 0.39 |
| 4148300239 |
CR38-11D-22, 11° Taper Cross Type Bit |
38 | 1 1/2 | 12 x 8 | 1 | 2 | 0.43 |
| 4148300240 |
CR41-11D-22, 11° Taper Cross Type Bit |
41 | 1 3/5 | 14 x 8 | 1 | 2 | 0.49 |
Competitive Advantage
• High grade tungsten carbide inserts
• Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment
Applications
• Suitable for small hole range
• Widely used in Dimensional Stone Quarrying Industry
• Widely used in Underground Mining Industry
