7' 11' 12' Taper Hard Rock Cross Type Bit / Chisel Bit for Mining

7' 11' 12' Taper Hard Rock Cross Type Bit / Chisel Bit for Mining thumbnail-1
7' 11' 12' Taper Hard Rock Cross Type Bit / Chisel Bit for Mining thumbnail-2
7' 11' 12' Taper Hard Rock Cross Type Bit / Chisel Bit for Mining thumbnail-3
7' 11' 12' Taper Hard Rock Cross Type Bit / Chisel Bit for Mining thumbnail-4
7' 11' 12' Taper Hard Rock Cross Type Bit / Chisel Bit for Mining photo-1
7' 11' 12' Taper Hard Rock Cross Type Bit / Chisel Bit for Mining photo-2
7' 11' 12' Taper Hard Rock Cross Type Bit / Chisel Bit for Mining photo-3
7' 11' 12' Taper Hard Rock Cross Type Bit / Chisel Bit for Mining photo-4
US$ 10 - 70 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
MIROC
Model Number:
Taper button bit
Contact Supplier Request Quote Chat Now
KSQ Technologies (Beijing) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
TianJin Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name MIROC
Model Number Taper button bit
Type Other, Cross type bit
Material Other, Tungsten Carbide, 45CrNiMoV
Use Other, mining

Application of Tungsten Carbide cross drill bit



Cross bit are mainly used in coal mining,metal mining,stoning and tube engineering.

1) Tapered connection: 7°11°12°

2) Thread connection: R22.R25.R28.R32.R38.T45.T51.

3) Bit diameter: 28-127mm.





7' 11' 12' Taper Hard Rock Cross Type Bit / Chisel Bit for Mining



Description & Specification:



Cross Type Bit, 7 ° , 11° , 12°
  Length (mm) Chisel Size (H x W) mm Weight (Kg)
1 30 12x12x8 0.29
2 32 12x12x8 0.31
3 33 12x12x8 0.33
4 34 12x12x8 0.34
5 35 12x12x8 0.36
6 36 13x12x8 0.37
7 38 14x12x8 0.43
8 40 15x12x8 0.47
9 41 15x12x8 0.49
10 42 15x12x8 0.51
11 43 15x12x8 0.53
12 45 17x14x8 0.58
13 48 17x14x8 0.67
14 50 19x14x8 0.72
15 55 20x16x10 0.92
16 60 20x16x10 1.19





Chisel Bit, 7 ° , 11° , 12°
  Length (mm) Chisel Size (H x W) mm Weight (Kg)
1 26 10x7 0.17
2 28 10x7 0.18
3 30 13.5x8 0.22
4 32 13.5x8 0.24
5 34 13.5x8 0.27
6 36 13.5x8 0.3
7 38 13.5x8 0.33
8 38 15x9 0.33
9 40 3.5x9.2 0.38
10 40 15x9.8 0.38
11 42 13.5x9.2 0.41
12 42 15x9.8 0.41
13 43 13.5x9.2 0.42





Company Profile:



KSQ Technologies (Beijing) Co. Ltd. is a company that shall cater to the needs of the construction and mining industries, with consideration on providing solutions to the following unique problems:

  • Hazardous environment
  • Acts, regulations, and other government guidelines that has to be followed
  • Significant differences in the way people work, mostly due o physical constraints
  • Avoiding downtime on major equipment which can cost tens of thousands of dollars per hour. The best solution with the most reasonable cost is a significant driver.
