11 Degrees Tapered Carbide Cross Type Bit

11 Degrees Tapered Carbide Cross Type Bit thumbnail-1
11 Degrees Tapered Carbide Cross Type Bit thumbnail-2
11 Degrees Tapered Carbide Cross Type Bit thumbnail-3
11 Degrees Tapered Carbide Cross Type Bit thumbnail-4
11 Degrees Tapered Carbide Cross Type Bit thumbnail-5
11 Degrees Tapered Carbide Cross Type Bit photo-1
11 Degrees Tapered Carbide Cross Type Bit photo-2
11 Degrees Tapered Carbide Cross Type Bit photo-3
11 Degrees Tapered Carbide Cross Type Bit photo-4
11 Degrees Tapered Carbide Cross Type Bit photo-5
Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
MIROC
Model Number:
CR29-11D-22 to CR41-11D-22
Contact Supplier Request Quote Chat Now
KSQ Technologies (Beijing) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing or Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name MIROC
Model Number CR29-11D-22 to CR41-11D-22
Type Other, Tapered Cross Type Bit
Material Tungsten Carbide
Use Metal Drilling

Specifications

High grade tungsten carbide inserts
Bit bodies manufactured from high grade steel and processed using state-of-the-art CN



Product Description



11°Tungsten Carbide Cross Bits Tapered Button Bit For Small Hole Range



Description

Tapered equipment affords drillers the ability to change drilling bits whilst still using the same drilling rod. Drillers choose tapered cross type bits if the goal is to minimize hole deviation in small hole range drilling. Different taper sizes have different characteristics when it comes to the “knock-off” index – the smaller angle will prevent the bit from spinning.


• Suitable for small hole range
• Widely used in Dimensional Stone Quarrying Industry
• Widely used in Underground Mining Industry


Color: Green,Blue or Based on Customer requirements


Material: Tungsten carbide and high strength alloy steel


Processing: CNC milling and proprietary heat treatment process


Type: 11° carbide cross bit



Applications


• Dimensional Stone Industry
• Underground Mining
• Tunneling



Competitive Advantage

• High grade tungsten carbide inserts
• Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment



specification



Part Number

Product Code and

Brief Description

Bit

Diameter

(mm)

Bit

Diameter

(inch)

Tip Size

(W x H, mm)

Front

Flushing

Holes

Side

Flushing

Holes


Weight

 (kg)
4148300233

CR29-11D-22, 11°

aper Cross Type Bit

 29 1 1/7 12 x 8 1 2 0.25
4148300234

CR30-11D-22, 11°

Taper Cross Type Bit

 30 1 1/6 12 x 8 1 2 0.26
4148300235

CR32-11D-22, 11°

Taper Cross Type Bit

 32 1 1/4 12 x 8 1 2 0.3
4148300236

CR33-11D-22, 11°

Taper Cross Type Bit

 33 1 2/7 12 x 8 1 2 0.32
4148300237

CR35-11D-22, 11°

Taper Cross Type Bit

 35 1 3/8 12 x 8 1 2 0.36
4148300238

CR36-11D-22, 11°

Taper Cross Type Bit

 36 1 3/7 12 x 8 1 2 0.39
4148300239

CR38-11D-22, 11°

Taper Cross Type Bit

 38 1 1/2 12 x 8 1 2 0.43
4148300240

CR41-11D-22, 11°

Taper Cross Type Bit

 41 1 3/5 14 x 8 1 2 0.49
