6x4 New 50 Ton Capacity China Mining Tipper Truck

Name: 6x4 New 50 Ton Capacity China Mining Tipper Truck
Brand: YUTONG
Availability: InStock

FOB Price

US$ 1 - 546,000 / Piece

1 Piece(Min. Order)

Port Qingdao Port Tianjin port Lianyungang port Shanghai port
Payment TermsT/T Money Gram PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Drive Wheel	6x4	Capacity (Load)	41 - 50t
Horsepower	351 - 450hp	Condition	New
Transmission Type	Manual	Emission Standard	Euro 2
Fuel Type	Diesel
Gross Vehicle Weight	26000	Place of Origin	Henan, China
Brand Name	YUTONG	Model Number	YTK76
Dimensions (L x W x H) (mm)	9150x3200x3950mm

Product Description

6x4 New 50 Ton Capacity China Mining Tipper Truck

Product Description

Main technical parameter

Item	Parameter
Overall Dimension (mm)	9150×3200×3950
Wheelbase (mm)	3800/1550
Wheel track of front wheel (mm)	2498
Wheel track of middle and rear wheels (mm)	2310
Capacity of standard compartment (m ³)	32
Capacity of rock compartment (m ³)	29
Kerb mass of entire vehicle (kg)	26000
Allowed total mass with full load (kg)	76000
Maximum vehicle speed (km/h)	49
Maximum gradeability (%)	29%
Maximum turning diameter (m)	≤21
Minimum ground clearance (mm)	≥360
Approach angle (°)	≥30°
departure angle (°)	≥45°
Lift time of lift system (s)	≤25
Landing time of lift system (s)	≤22
Maximum angle inclination of lift system (°)	≤52
Color	White
Engine model	WD12G375E211
Rated power of engine (kw/hp)	276/375
Rated power of engine (rpm)	2200
Engine torque (N.m)	1500
Air intake way of engine	Three-level oil filter, combined type air filter and turbo charger
Clutch	Diaphragm spring 430
Transmission	9JSD180
Front axle (t)	Special axle for 16t-level enhanced type mining truck
Middle and rear axles (t)	Special axle for 30t-level enhanced type mining truck
Front suspension of suspension system	Enhanced longitudinal-installed leaf spring, bi-directional telescopic shock absorber
Rear suspension of suspension system	Enhanced type balanced suspension
Cab	Bias, turnover, suspended and anti-rollover cab
Tire	14.00-24 24PR
Service brake	Dual-circuit brake
Parking brake	Air break breaking by spring energy storage chamber
Auxiliary braking	Engine exhaust brake

Optional Equipment

project		parameter
Transmission	FAST 9JSD180A
Clutch	clutch430
Carriage	Rock carriage	Bottom 16, side 12, rear 12, front 10, tail raise 8°
Carriage	Rock carriage	Bottom 20, side 12, no rear , tail raise12
Else	Tire	14.00-24-36PR
	Exhaust brake +Telma eddy current retarder (Hande axle optional)
	Iron fuel oil tank	600L
	Muffler exhaust
	ZF steering pump
	Water spraying device	320L 550L
	Stone plate
	Fan JD211-4B
	One way onboard monitoring system SV56E1
	Rotary warning light XVR-13B05
	Hour meter 701RN001O1248D

Performance

	1.The carriage during flat loading may reach 32 cubic meters, and 37 cubic meters during stack loading. The large excavator may be used for construction. The solo vehicle may load more material, reduce vehicle density in the mine area and improve transportation efficiency. 2.The vehicle is coupled with the high quality and performance Weichai engine boasting of strong power and high reliability. 3.The enhanced Pengxiang axle provided boasts of super strong carrying capacity, super high reliability and powerful brake performance. In the meantime, the frame and suspension with optimal design endows such vehicle with powerful carrying capacity and high reliability. 4.Rigid welding frame, adopt t14mm high strength steel plate, height 450 (height of main and auxiliary beam structure within the industry 530), middle and rear wheelbase 2310mm. Owing to the wide whole unit, big wheelbase, low gravity center and high stability, the vehicle runs more steadily. 5.Owing to the newly-designed drum brake, and combined with the powerful brake torque of the axle, the vehicle boasts of good brake performance. In the meantime, the skeleton-type cab used boasts of the sturdy structure so that the personal safety of the driver can be secured in an all-round manner.

Transportation Plan

Intelligent management system from real-time monitoring of equipment and personnel management needs to solve two aspects, the use of remote fault diagnosis, maintenance reminders, and data analysis solution extends the application requirements. Real-time monitoring equipment provided by satellite positioning system location, track information, provide work attitude, fault alarm information through the controller, providing photos and video information by the video module, the job status provided through other ports, fuel tank (optional) information.

Driver information system through the realization of staff card, work log management, system permissions through the platform division. Through remote diagnosis, maintenance reminders, data storage and achieve an extension of value-added applications.

Users using a Web browser and mobile App for equipment and personnel to implement dynamic management. Service platform for different customers in different business requirements also analyzed output data and statistical reports and analysis reports. The methods of data in real-time, high accuracy, good visibility, the device dynamic management and in-depth data to provide a flexible and efficient platform for mining.

Our Services

"12380"Service after sale. We can offer:

1.After receiving the customer mobile, we will help customer solve problem through removing the resources of
Yutong service and reply the customer clearly in one hours;

2: To improve the service quality all the time, in 2working days of the end of on-sit service, we will pay a return visit
about the satisfaction of after sale service;

3: To comprehensive systematically and professionally maintenance and repair for the customer product, we will
have 3 times On-Site Inspection forwardly in warranty period;

8:The service engineer will solve problem in 8 hours after getting to on-sit. If the problem is not solve ,the service
engineer can not leave the on-sit;

0: To eliminate customer worries, from receiving order to product scrapping, Yutong will provide full reliance,
seamless docking and service in the period of product using.

Yutong Heavy Industry is China's top 500 enterprises Yutong Group's core subsidiary, is a leading supplier of specialized mining, infrastructure and sanitation machinery and equipment package of solutions. The company is the cradle of Chinese construction machinery design and manufacturing, since 1958, China's first hydraulic torque converter, the first power shift transmission, the first self-propelled scrapers, the first large horsepower tire type tractors, more than 30 "China's first" all born here! factory occupies 2102 acres, with more than 3,000 people, including more than 470 man-made construction machinery senior technical staff, and has academician workstation and provincial enterprise technology center.

Yutong Heavy Industries as a quality supplier of PLA, every year a large loaders and bulldozers to the military. We also provide the United Nations had as loaders, bulldozers and wreckers, and obtained the creation of the United Nations awarded the Star of Science Award.

Our company is China's first loader KD line exporter, currently this KD line services in Iran, the annual amount of 300 assembly, and its products can cover the Middle East, many countries such as: Saudi Arabia, Turkey and Azerbaijan. Also Our rotary drilling rig, successfully sold to the United States five devices, and job conditions in Alaska minus 50 degrees. Our product is in Africa an affirmative president of Nigeria, the African business people and our next president our photo equipment. Our sanitation garbage package of solutions and services in Ghana is the country for the African brothers to improve their living environment contribute our part. In South America, Cuba and Venezuela, we are the government's long-term strategy for its suppliers. Rotary Drilling Division I Participation in 2008 Olympic Games in the Bird's Nest construction work, and successfully laid the first pile.
