Home > Products > Mining Machinery > China 6x4 Hot Sale 30 Ton Mining Dump Truck
China 6x4 Hot Sale 30 Ton Mining Dump Truck
- 193 Piece / Pieces per Month
- Qingdao Port Tianjin port Lianyungang port Shanghai port
- T/T Credit Card
Product Details
Drive Wheel: | 6x4 | Capacity (Load): | 31 - 40t | Horsepower: | 351 - 450hp |
Condition: | New | Transmission Type: | Automatic | Emission Standard: | Euro 2 |
Fuel Type: | Diesel | Gross Vehicle Weight: | 22000 | ||
Place of Origin: | Henan, China | Brand Name: | YUTONG | Model Number: | YT3621 |
Dimensions (L x W x H) (mm): | 8750x3200x3700 |
Product Description
China 6x4 Hot Sale 30 Ton Mining Dump Truck
Main Technical Parameters
Parameter |
| |
Overall Dimension (mm) | 8630X2580X3500 | |
Wheelbase (mm) | 3975/1400 | |
Wheel track of front wheel (mm) | 2035 | |
Wheel track of middle and rear wheels (mm) | 1860 | |
Capacity of standard compartment (m3) | 20 | |
Capacity of rock compartment (m3) | 19 | |
Kerb mass of entire vehicle (kg) | 18000 |
|
Allowed total mass with full load (kg) | 50000 | |
Maximum vehicle speed (km/h) | 68 | |
Maximum gradeability (%) | 30% | |
Maximum turning diameter (m) | ≤20 | |
Minimum ground clearance (m) | ≥330 | |
Approach angle (°) | ≥28° | |
departure angle (°) | ≥23° |
|
Lift time of lift system (s) | ≤18 | |
Landing time of lift system (s) | ≤20 | |
Maximum angle inclination of lift system (°) | ≤52 | |
Engine model | Weichai WP10.340E32 | |
Rated power of engine (kW/hp) | 250/340 | |
Rated power of engine (rpm) | 2200 | |
Engine torque (N.m) | 1350(1500) |
|
Color | Optional | |
Driving Type | Left & Right Hand Drive | |
Air intake way of engine | Desert air cleaner+ Turbocharger | |
Clutch | 430 mm diameter friction disk | |
Transmission | 9JSD150A | |
Front axle (t) | Hande 9.5t axle | |
Middle and rear axles (t) | Hande 16t axle |
|
Frame(mm) | Riveted structure 850x320x90 (8+7+8) | |
Cab | Bias, turnover, suspended and anti-rollover cab | |
Tire | 12.00R20 | |
| Dual-circuit brake | |
Parking brake | Air break breaking by spring energy storage chamber | |
Auxiliary braking | Engine exhaust brake/eddy-current retarder auxiliary brake + exhaust brake |
Serial number | project | parameter | |
1 | Weichai WP12.380E32 | Rated power of engine (kW/hp) | 279/380 |
Rated power of engine (rpm) | 2200 | ||
Engine torque (N.m) | 1700/(1500rpm) | ||
2 | Clutch | clutch | 430 mm diameter |
3 | Fuel tank | FAST 10JSD180 | |
4 | Water tank of the wheel water spray system | Volume in (L) | 320 |
5 | Retarder | KEMI eddy-current retarder | |
6 | Else | Independent heating | |
Monitoring system | |||
Hour meter | |||
Rotary warning lamp added | |||
Internet of Vehicle |
1.Wide-body straight beam frame made of imported high-strength alloy is used. The height of the longitudinal beam is320mm. The main beam and inner lining beam have wall thickness of8mmand7mm, respectively. 2. The tail beam adopts back to back structure. The front axle adopts HandeMANtech 9.5t axle. Therear axle adopts MAN tech Hande 16t casting axle. 3. Owing to strong power Weichai engine, Fast transmission with twin countershaft and large center distance structure, automotive-like exquisite interior as well as excellent balance shaft and clutch release fork assembly structure, the reliability of the whole vehicle has greatly improved. 4. Rigid welding frame, adopt t14mm high strength steel plate, height 450 (height of main and auxiliary beam structure within the industry 530), middle and rear wheelbase 2310mm. Owing to the wide whole unit, big wheelbase, low gravity center and high stability, the vehicle runs more steadily. | |
5. Owing to the newly-designed drum brake, and combined with the powerful brake torque of the axle, the vehicle boasts of good brake performance. In the meantime, the skeleton-type cab used boasts of the sturdy structure so that the personal safety of the driver can be secured in an all-round manner 6. The appearance modeling of the whole vehicle is well-designed. The appearance has modern design, which is sturdy and strong like mining machinery, also is harmonious and graceful like an automobile. It perfectly combines the appearance style designs of engineering machineries and automobiles. 7. In the cab, luxury and exquisite interior, streamlined instrument desk, combination instrument and environmentally friendly flame retardant interior materials create a comfortable operating environment, reflecting the design concept of manufacturing the construction machinery like a sedan. |
"12380"Service after sale. We can offer: 1.After receiving the customer mobile, we will help customer solve problem through removing the resources of Yutong service and reply the customer clearly in one hours; 2: To improve the service quality all the time, in 2working days of the end of on-sit service, we will pay a return visit about the satisfaction of after sale service; 3: To comprehensive systematically and professionally maintenance and repair for the customer product, we will have 3 times On-Site Inspection forwardly in warranty period; 8:The service engineer will solve problem in 8 hours after getting to on-sit. If the problem is not solve ,the service engineer can not leave the on-sit; 0: To eliminate customer worries, from receiving order to product scrapping, Yutong will provide full reliance, seamless docking and service in the period of product using. |
Yutong Heavy Industry is China's top 500 enterprises Yutong Group's core subsidiary, is a leading supplier of specialized mining, infrastructure and sanitation machinery and equipment package of solutions. The company is the cradle of Chinese construction machinery design and manufacturing, since 1958, China's first hydraulic torque converter, the first power shift transmission, the first self-propelled scrapers, the first large horsepower tire type tractors, more than 30 "China's first" all born here! factory occupies 2102 acres, with more than 3,000 people, including more than 470 man-made construction machinery senior technical staff, and has academician workstation and provincial enterprise technology center. Yutong Heavy Industries as a quality supplier of PLA, every year a large loaders and bulldozers to the military. We also provide the United Nations had as loaders, bulldozers and wreckers, and obtained the creation of the United Nations awarded the Star of Science Award. Our company is China's first loader KD line exporter, currently this KD line services in Iran, the annual amount of 300 assembly, and its products can cover the Middle East, many countries such as: Saudi Arabia, Turkey and Azerbaijan. Also Our rotary drilling rig, successfully sold to the United States five devices, and job conditions in Alaska minus 50 degrees. Our product is in Africa an affirmative president of Nigeria, the African business people and our next president our photo equipment. Our sanitation garbage package of solutions and services in Ghana is the country for the African brothers to improve their living environment contribute our part. In South America, Cuba and Venezuela, we are the government's long-term strategy for its suppliers. Rotary Drilling Division I Participation in 2008 Olympic Games in the Bird's Nest construction work, and successfully laid the first pile. |
Intelligent management system from real-time monitoring of equipment and personnel management needs to solve two aspects, the use of remote fault diagnosis, maintenance reminders, and data analysis solution extends the application requirements. Real-time monitoring equipment provided by satellite positioning system location, track information, provide work attitude, fault alarm information through the controller, providing photos and video information by the video module, the job status provided through other ports, fuel tank (optional) information.
Driver information system through the realization of staff card, work log management, system permissions through the platform division. Through remote diagnosis, maintenance reminders, data storage and achieve an extension of value-added applications.
Users using a Web browser and mobile App for equipment and personnel to implement dynamic management. Service platform for different customers in different business requirements also analyzed output data and statistical reports and analysis reports. The methods of data in real-time, high accuracy, good visibility, the device dynamic management and in-depth data to provide a flexible and efficient platform for mining. |
We are military equipment supplier, our original facotry is founded at 1958. Good quality and competitive price is our advantage.
For quality guarate, we give one year guarantee, and with 24hours response principle for better service. We have more than 30 agency all over the world, you can get the most convenient service by nearest agency.
We accept T/T, L/C, D/P, D/A,even L/G. |
