The main technique parameter |
unit |
YTQH800 |
Level of compaction |
t.m |
800 |
Pemitido hammer weight |
t |
40 |
Wheelbase chassis |
mm |
7100 |
Chassis width |
mm |
6250 |
Shoe width |
mm |
850 |
Arm length |
m |
20-26(29)m |
Working angle |
° |
60-77 |
Maximum lift height |
m |
27 |
Working radius |
m |
7.0-17.0 |
Tractive force |
t |
15-20 |
Lifting speed |
m/min |
0-50 |
Rotation speed |
r/min |
0-1.5 |
Displacement read speed |
km/h |
0-1.6 |
Grade ability |
% |
30 |
Engine power |
kW |
294 |
Rated motor speed |
r/min |
1900 |
Weight of complete system |
t |
119 |
Weight counterbalance |
t |
35 |
Host weight |
t |
40 |
Host size (length * width * height) |
mm |
9830*3400*3400 |
Introduction caterpillar type compressor pressure liquid YTQH800
YTQH800 machine hydraulic compaction of tire tracks is a hydraulic compactor equipment that can turn completely and has a set of several sections of arms bragero, independently created by Yutong Heavy Industries to meet market demand, combined with many years of experience to produce lifting and compaction. This model is efficient and reliable, it has a nice look and fully satisfies the conditions of compaction and has reached the advanced level in terms similar products interior.
The construction of compression has wide application range: The maximum stroke can reach 800 t / m without shelf porch, can reach 1800 t / m with shelf porch; in good condition building you can reach 2000 t / m.
The device has excellent dynamic force yields: Weichai 294kw engine emission National level III, which has great power, stable performance, economical, protects the environment and has low costs; two pumps of variable emission general value of 190 emission amount of 120kw with high transmission efficiency.
The chassis has high hardness, high confiabibilida, excellent yields: specific structure strengthened chassis has hit caterpillar length and width of 8010mm 6250mm, applies the back support of the central diameter of 2150mm with high hardness and good stabilities; the distance between the chassis and the earth is greater than 426mm, the pressure ratio is 0.085MPa ground, with plenty of crossover; Extensible has foot forward and rear support beams that can reduce impacts of support work efficiently.
Great lift arm hardness: The lift arm is welded tube materials largest hardness of 770MPa hardness level, the overall dimension of the tube is φ114X8, with good rigidity, light weight and high bearing capacity. The upper arm carries a structure of "head goose" is more suited to compact; winch mechanism hinged locking pawl can ensure that the placement of the lifting arm is safe and reliable.
The lifting súcula has great force of each wheel: use two lifting súculas working level M7 with function free fall hook, the pulling force of each wheel reaches up to 15-20 tons, the maximum speed of each wheel reaches up to 52m / min, the brake always closed tucked inside can ensure reliable hammer brake at the same time can raise the hammer at the same time that can double the speed type.
The easy and flexible operation: The control system high pressure applied by hand control box type guide hand with sensible and flexible load sensor; rotation structure is freely controllable sliding yields, stable operation without impacts.
It is able to work for long time with great power: The system of individual radiator large power installed in the system liquid pressure can ensure working with all power long engine and high pressure system without causing over heat power great. The fuel tank has increased, the actual volume of the fuel tank reaches 800 liters, which can ensure a day's work efficiently.
Reliable security: You have installed electronic instrument cluster, it has concentrated control of motor data and automatic alarm; They were installed safety devices such as device lock rotation of the rotary table, the tilt prevention apparatus behind the lift arm, the limiter rear position of variable amplitude, etc., ensuring reliable and safe working.
The operation is comfortable: the cab is connected to the buffer, the view is wide, is beautiful and has a safety net. Humanistic design of cabin interior driver are installed damping chairs, fan and heating, and you can select the MP3 player and air conditioning heat and cold that provides comfortable operation and good working conditions.
Easy transportation: The size of the overall external appearance is 9830X3400X3400mm machine were installed four tanks of liquid oil pressure in the chassis for easy disassembly and car caterpillar above. During transportation need to disassemble the arm rack, load, front foot support and cushioning rear shelf, left and right track, the maximum weight of each unit is 40 tons which can perform transfer three cars to costs low. Weight distribution type support multiple parts, is easier to install, disassemble and transport. The outer size is 1520X1720mm arm shelf, it can be installed parallel in two rows.
