Taper 7 degree chisel bit, 32mm 34mm 36mm 38mm 40mm 42mm for small hole drilling



             KSQ Technologies(Beijing)Co.Ltd





Product Description

                                                              Chisel Bit- Taper 7 degree

Basic Information:



Product Name:

Chisel Bit-Taper 7 degree

Buttons(H x w)

13.5x8mm

Diameter(mm)

26mm-43mm

Diameter(inch)

1 inch- 1 2/3 inch

Material:

High strength alloy steel

Type

Standard Type, Flat Chipways Chisel Bit, Oblique Chipways Chisel Bit

Color

 Black or based on customer requirements.

MOQ:

No MOQ required for testing and trial order



Specification:



Bit Dia. For class of rock Buttons Taper Weight
mm inch HxW kg
26 1     10~14 10x7 7º 0.17
28 1 1/9 10~14 10x7 7º 0.18
30 1 1/6 8~12 13.5x8 7º 0.22
30 1 1/6 10~14 13.5x8 7º 0.22
32 1 1/4 8~12 13.5x8 7º 0.24
32 1 1/4 10~14 13.5x8 7º 0.24
34 1 1/3 8~12 13.5x8 7º 0.27
34 1 1/3 10~14 13.5x8 7º 0.27
36 1 3/7 8~12 13.5x8 7º 0.3
36 1 3/7 10~14 13.5 x 8 7º 0.3
38 1 1/2 8~12 13.5x8 7º 0.33
38 1 1/2 10~14 13.5x8 7º 0.33
38 1 1/2 8~12 15x9 7º 0.33
38 1 1/2 10~14 15x9 7º 0.33
40 1 4/7 8~12 13.5x9.2 7º 0.38
40 1 4/7 10~14 13.5x9.2 7º 0.38
40 1 4/7 14~16 13.5x9.2 7º 0.38
40 1 4/7 16~18 15x9.8 7º 0.38
40 1 4/7 8~12 15 x 9.8 7º 0.38
40 1 4/7 10~14 15x9.8 7º 0.38
40 1 4/7 14~16 15x9.8 7º 0.38
40 1 4/7 16~18 15x9.8 7º 0.38
42 1 2/3 8~12 13.5x9.2 7º 0.41
42 1 2/3 10~14 13.5x9.2 7º 0.41
42 1 2/3 14~16 13.5x9.2 7º 0.41
42 1 2/3 16~18 13.5x9.2 7º 0.41
42 1 2/3 8~12 15x9.8 7º 0.41
42 1 2/3 10~14 15 x 9.8 7º 0.41
42 1 2/3 10~14 15x9.8 7º 0.41
42 1 2/3 16~18 15x9.8 7º 0.41
43 1 5/7 8~12 13.5x9.2 7º 0.42
43 1 5/7 10~14 13.5x9.2 7º 0.42
43 1 5/7 8~12 15x9.8 7º 0.42
43 1 5/7 10~14 15x9.8 7º 0.42




 HS Code: 82071990

Product Pictures:

 Taper 7 degree chisel bit, 32mm 34mm 36mm 38mm 40mm 42mm for small hole drillingTaper 7 degree chisel bit, 32mm 34mm 36mm 38mm 40mm 42mm for small hole drilling



Applications:

• small hole drilling





Packaging & Shipping



 1. Carton or wooden box

 2. Package pictures

Taper 7 degree chisel bit, 32mm 34mm 36mm 38mm 40mm 42mm for small hole drilling
