T38 Retrac Rock Drill Bit, Ballistic Buttons

T38 Retrac Rock Drill Bit, Ballistic Buttons thumbnail-1
T38 Retrac Rock Drill Bit, Ballistic Buttons photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
MIROC
Model Number:
R1264-T38-B to R1389-T38-B
Contact Supplier Request Quote Chat Now
KSQ Technologies (Beijing) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing or Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name MIROC
Model Number R1264-T38-B to R1389-T38-B
Type Other, Retrac Button Bit
Material Tungsten Carbide
Use PCB Drilling

Specifications

High grade tungsten carbide inserts
Bit bodies manufactured from high grade steel and processed using state-of-the-art CN




Product Description



  • Description:
    • This type of bit is well known for its wear resistance on soft to medium-hard rock formations (between 55MPa to 165MPa compressive strength)
    • Featuring ballistic tungsten carbide inserts that is known to have high penetration rate, but has weak configuration against carbide fracture
  • Applications:
    • Underground mining
    • Tunneling
  • Quick detail:
    • Widely used drifting and tunneling
    • Bit face design is ideal for soft to medium rock formations
    • With retract wings to help guide the bit in and out of the hole
    • Effective in straight hole drilling
    • Featuring ballistic tungsten carbide inserts for high penetration rate
  • Competitive advantages:
    • High grade tungsten carbide inserts
    • Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment
    • Part number Bit diameter (mm) Bit diameter (inch) Front buttons (no x mm) Gauge buttons (no x mm) Angle Front flushing holes Side flushing holes Weight (kg) Product code and brief description
      4148300750 64 2 1/2 4x10 8x10 30° 2 - 2.2 R1264-T38-B, T38 Retrac Button Bit, Ballistic Buttons
      4148300751 64 2 1/2 3x10,  1x10 6x11 35° 3 - 2.2 R1064-T38-B, T38 Retrac Button Bit, Ballistic Buttons
      4148300752 70 2 3/4 4x11 8x11 40° 2 - 2.4 R1270-T38-B, T38 Retrac Button Bit, Ballistic Buttons
      4148300753 70 2 3/4 3x10,  1x10 6x13 35° 3 - 2.4 R1070-T38-B, T38 Retrac Button Bit, Ballistic Buttons
      4148300754 70 2 3/4 4x10, 1x10 8x11 35° 4 - 2.4 R1370-T38-B, T38 Retrac Button Bit, Ballistic Buttons
      4148300755 76 3  4x11 8x11 40° 2 -  3.3 -
      4148300756 76 3 4x11,  1x11 8x10 35° 4 - 3.3 R1376-T38-B-1, T38 Retrac Button Bit, Ballistic Buttons
      4148300757 76 3 4x11,  1x11 8x12 35° 4 - 3.3 R1376-T38-B-2, T38 Retrac Button Bit, Ballistic Buttons
      4148300758 89 3 1/2 4x13 8x13 40° 2 - - R1276-T38-B, T38 Retrac Button Bit, Ballistic Buttons
      4148300759 89 3 1/2 5x13 8x13 35° 2 - - R1389-T38-B, T38 Retrac Button Bit, Ballistic Buttons
      4148300760 89 3 1/2 6x11 8x12 35° 2 - 4.8 R1489-T38-B-1, T38 Retrac Button Bit, Ballistic Buttons
      4148300761 89 3 1/2 4x13,  1x11 8x13 35° 4 - 4.8  R1489-T38-B-2, T38 RetracButton Bit, Ballistic Buttons
      4148300762 89 3 1/2 4x13,  1x13 8x13 35° 4 - 4.8 R1389-T38-B, T38 Retrac Button Bit, Ballistic Buttons





Packaging & Shipping

  Packaging:Carton or Wooden Box
