24 mm Chisel Bits shank 22mm x 108mm Integral Drilling Rods
- 30000 Piece / Pieces per Month
- Tianjin Port
- T/T L/C D/P D/A Credit Card PayPal
- API-7-1 Standard single cone drill bit
- 6 7 11 12 degree Diameter 32mm Taper Knock off drill bit
- Oilfield cementing tool cement head for drilling rig
- Oilfield Tools API 5CT double dual single plug cementing Head
- API 7K Single Pulg/Double Plug Cement Head For Cement
- Oilfield double/single plug casing cement head for cementing equipment
Product Details
Place of Origin: | Shandong, China | Brand Name: | Miroc | Model Number: | Integral Drilling Rods |
Type: | Other, Drill Rod, Integral Drilling Rods | Machine Type: | Drilling Tool | Certification: | API |
Material: | Other, Carbon Steel, High quality carbide and high quality steel | Processing Type: | Forging | Use: | Other, tunneling, mining,quarrying |
Product Description
The H22 Integral drills steels, H22 x 108 mm shank, are the most common type within the Dimensional Stone Quarrying Industry. The product range includes a Ø26 - 40 mm bit diameters and lengths from 0.4 – 7.2 meters.
• Suitable for small hole range
• Widely used in Dimensional Stone Quarrying Industry
Color: Based on Customer requirements
Material: Tungsten carbide and high strength alloy steel
Processing: CNC milling and proprietary heat treatment process
Product Name: | hard rock Mining Integral drill steel,Integral drill rod | |||
Types | Tapered drill rods, Integral drill rods, Plug hole rods | |||
Application:: | Tapered drill rods are used in granite and marble quarry, gold mine, railway, tunnel, etc. for drilling | |||
Material: | High quality carbide and high quality steel | |||
MOQ: | No requirement for testing and trial order |
Applications of integral drill steel
• Dimensional Stone Quarrying Industry
• Underground Mining
• Tunneling,quarrying
Competitive Advantage
• High strength chromium-molybdenum steel with high fatigue strength and excellent wear resistance
• High grade tungsten carbide inserts
Specification of integral drill steel
Types of drill rods | Specifications | Length (mm) | Shank | Weight (kg) |
Tapered drill rods | Taper Angle: 4, 6, 7, 11, 12 degree | 400mm to 8000mm | Hex22mm*108mm Hex25mm*159mm Hex19mm*108mm | 1.7 - 24.9 |
Integral drill steel | Bit diameter: 26mm, 28mm, 30mm, 32mm, 34mm, 36mm, 38mm, 40mm, 42mm | 400mm to 4800mm | 3 – 15.4 | |
Plug hole rods | Chisel bit diameter: 17mm, 20mm, 22mm | 150mm to 710mm | 0.6 - 2.9 |
