Surveillance camera/high speed Dome camera 530TVL
Introduction Features
It can set address & protocol in speed dome OSD menu
Powerful Sony original module FCB-CX1010, 1/4” Ex-view HAD CCD inside,530TVL, Wide Dynamic Range function.
Remote update flash of speed dome by RS485 bus
Automatically identify PEAMRAIN protocol or PELCO D/P protocol
Automatically identify SANYO, SONY, HITACHI, CNB series etc. camera module.
Powerful OSD menu for setup of Programmable Functions
With function of auto focus, auto iris, auto white balance and auto backlight compensation etc. to have clear camera scene at any time.
Built-in linear power for anti-surge and anti-Lightning protection
Alarm (8ch inputs & 2 repay out), smoked cover, Pelco C, Manchester communication, available to application.
Built-in function of protocol converter, to support RS485 communication or Manchester code.
Preset position storage function, it can save maximum 256 preset.
8 cruise tours, every tour can call 32 preset.
4 Pattern tours, to save the scan route by joystick.
1 automatic scan, the scope of two limits can be scanned gradually, the scanning steps are optional.
Automatic recover to movement before power failure.
Time start-up function, to start movement in time table have been set.
Power-up action, preset, cruise tour, pattern tour, auto scan, etc. available for it.
Park action, preset, cruise tour, pattern tour, auto scan, etc. available
360° continuous panning.
-5°~90° tilting rotation, automatic flip function, continuous tilting between -5°to 185°.
Privacy masking function, Up to 24 Zones, 8 Zones Masked Simultaneously in One Camera Image .
Limit setting, to set the pan or tilt movement in a scope.
On-Screen display: Compass, Pan, Tilt, Zoom ratio and temperature
Specifications for Pan-tilt:
Address |
0~255 |
Pan range |
360°Continue |
Tilt range |
0°~90° Flip |
Manual speed Pan |
0.05~240°/Sec |
Manual speed Tilt |
0.05~180°/Sec |
Preset speed |
240°/Sec |
Preset accuracy |
±0.50° |
Preset |
256 |
Remote firmware updating and setup |
to update firmware by RS485, to set ID by RS485 |
CruiseTours |
8 Programmable(Dwell time speed preset point) |
Speed setup for cruise tour |
Yes |
PatternTours |
4 Programmable |
Auto Scan |
1 Programmable (355° scan ) |
Alarm |
Optional, 8 inputs, 2 outputs |
Temperature setup and display |
Temperature alarm & display on screen |
Time adjustment |
to adjust Time by broadcasting |
Date/Time setup and display |
Date/time display on screen and modify |
Timer Programming |
timer action |
Integrate multi-protocol |
Pelco_D/P, PEARMAIN, Pelco C (optional) |
Protocol Automatic identify |
Pelco_D/P, PEARMAIN |
Total working time recording |
to record total working time and time exceed limit |
Home position |
Yes, preset, cruise tour, pattern tour, auto scan, etc. available |
Password protection |
Yes |
Long-focus speed-limited |
Yes |
Broadcasting address |
Yes |
Intelligent power-off memory current setting and state |
Yes |
anti-surge and anti-Lightning protection |
Yes |
OSD menu operation |
Yes |
Supporting camera |
Automatic identify(Sony,Hitachi, Sanyo, LG, CNB ) |
Camera menu operation |
Yes |
Camera character programming |
20 character |
Privacy masking |
Yes |
Ingress Protection IP66 |
Yes |
Operating Temperature |
–55℃~65℃ |
Humidity |
0%~90% (Non condensing) |
Heater operate |
(-5)℃ on +5℃off |
Power |
24VAC±25%,1.5A--2A,60Hz/50Hz |
Consumption |
heater off 12W heater on 37W |
communication |
RS485 (+/-) orManchester |
Connection |
BNC cable |
Camera
Image sensor |
1/4-type Ex-view HAD CCD |
Number of total pixels |
Approx. 440,000 pixels |
Lens |
36x optical zoom, f=3.4 mm(wide) to122.4 mm(tele), F1.6 to F4.5 |
Digital zoom |
12x (432x with optical zoom) |
Angle of view (H) |
57.8° (wide end) to 1.7° (tele end) |
Minimum working distance |
320 mm (wide end) to1,500 mm(tele end) |
Sync system |
Internal / External (V-lock) |
Minimum illumination |
1/60 s mode: 1.4 lx (typical) (F1.6, 50 IRE). 1/4 s mode: 0.1 lx (typical) (F1.6, 50 IRE) |
Horizontal Resolution |
530TVL |
S/N ratio |
More than 50 dB |
Electronic shutter |
1/1 to 1/10,000 s, 22 steps |
White balance |
Auto, ATW, Indoor, Outdoor, One-push WB, Manual WB |
Gain |
Auto / Manual (-3 to 28 dB, 16 steps) |
AE control |
Auto, Manual, Priority mode (shutter priority & iris priority), Bright, EV compensation, Backlight compensation, Slow AE) |
Wide dynamic range |
On / Off |
Backlight compensation |
On / Off |
Privacy zone masking |
On/Off (8 masks per view/24 masks presets in the entire viewing range when integrated into a PTZ camera - 14 colors, mosaic) |
Character generator |
Mode display/Multi-line OSD (OSD has priority over Mode display) |
Focusing system |
Auto (Sensitivity: normal, low), One-push AF, Manual, Infinity, Interval AF, Zoom Trigger AF |
Picture effects |
E-Flip, Nega Art, Black & White, Mirror Image |
Camera operation switch |
Zoom tele, Zoom wide |
Video output |
VBS: 1.0 Vp-p (sync negative), Y/C |
Camera control interface |
VISCA (TTL signal level), baud rate: 9.6 Kb/s, 19.2 Kb/s, 38.4 Kb/s, 1 or 2 Stop bit selectable |
Storage temperature |
(-)20 to60 °C(-4 to140 °F) |
Operating temperature |
0 to50 °C(32 to122 °F) |
Power consumption |
6 to 12 V DC/2.6 W (motors inactive),4.9 W (motors active) Mass230 g(8.1 oz) |
Dimensions |
Dimensions (W x H x D) 50.0 x 57.5 x87.9 mm(2 x 2 3/8x 3 1/2inches) |
1. Does the product come with the cables or do they have to be ordered seperately?
All of the devices are assembled with cable and power adapter.
2. Are you a trade company or manufacturer?
We are a professional manufacturer and also a trade company.
3. What is your advantage in this field?
We have been designing & producing matrix switcher, keyboard controller and other surveillance system related products for almost 20 years in China. The compatibility & quality of our products is assured.
4. Can you design product with special functions for me?
We are professional OEM/ODM manufacturer, we are able to design the product according to your requirement as possible as we can.
5. If I am not clear about how to use the products, what should I do?
Each of our products has a manual, our professional after-sales team will support you in 24 hours if you have any question.
With years of export experience along with excellent quality, advanced services and competitive prices, PEARMAIN has won numerous customers' trust and support.
All packages are well protected in the cartons, so the products can be protected from damages.
Time of shipment ranges 5-7days according to different places.
For big orders, we will arrange Air Cargo or Ocean Freight with low delivery cost. Also, we can ship out with your specified shipment agent.
