ENIG High Frequency Multilayer PCB 10 Layer , 1 OZ Copper Thickness PCB
Quick Detail:
1.Number of Layers: 610layers
2.1.6mm thickness, 1oz copper
3.Multilaye High Frequency pcb
4.Surface finish : ENIG
5.Red solder mask
6. White silkscreen
Specification:
Material |
FR4 |
Layer count |
10 layers |
Board thickness |
1.6mm |
Copper thickness |
1oz |
Minimum drill size |
0.2mm |
Minimum trace & gap |
0.2mm |
Surface finish |
ENIG |
Applications |
Consumer product |
Special Technology |
High Frequency |
copper filled vias |
Applications:
Consumer Computers, televisions, cameras, digital video recorders (DVR), handheld products, LED, etc.
Military Satellite, radar, airplane, control unit, communication equipment .etc.
Medical Magnetic resonance imaging (MRI), computed tomography (CT), emergency response defibrillation units, patient monitoring, implantable devices, robotic surgery systems, biometrics and diagnostic equipment, etc.
High End Computing and Storage High performance computer and server, mainframe system and storage equipment, memory, etc.
Industry Power supply, main control panel, monitor, CCTV products,automotive control equipment, industry robot, access control products etc
Test & Measurement Power meters, electricity tester, thermal tester, light tester, network tester, gas and oil tester, infrared products, semi-conductor test equipment, DUT and probe cards, wafer inspection systems, etc.
Automotive Passenger safety systems, engine control systems, air bags, traction control products, etc.
Comunications
VOIP, Traditional Telecomunication equipment, FTTP, Multimedia service, Powe amplifiers, IT infrastructure products, wireless infrastructure products, splitters and combiners, high power transistors, etc.
Computer Peripherals High end printers, cable modem, IP telephones, consumer and office products, wireless routers, banking system etc.
PCB Circuit Board
NO |
ITEM |
Technical capabilities |
1 |
Layers |
1-20 layers |
2 |
Max. Board size |
508×610 mm |
3 |
Min. board Thickness |
2-layer 0.12mm |
4-layer 0.4mm | ||
6-layer 0.6mm | ||
8-layer 0.90mm | ||
10-layer 1mm | ||
4 |
Min. line Width/Space |
0.127mm(4mil) |
5 |
Max. Copper thickness |
5OZ |
6 |
Min. S/M Pitch |
0.075mm(3mil) |
7 |
Min. hole size |
0.15mm(6mil) |
8 |
Hole dia. Tolerance (PTH) |
±0.05mm(2mil) |
9 |
Hole dia. Tolerance (NPTH) |
+0/-0.05mm(2mil) |
10 |
Hole position deviation |
±0.05mm(2mil) |
11 |
Outline tolerance |
±0.10mm(4mil) |
12 |
Twist & Bent |
<0.7% |
13 |
Insulation Resistance |
100MΩ Normal |
14 |
Electric strength |
>1.3kv/mm |
15 |
S/M abrasion |
>6H |
16 |
Thermal stress |
288°C 20Sec |
17 |
Test Voltage |
50-300V |
18 |
Min. blind/buried via |
0.15mm (6mil) |
19 |
Surface Finished |
HAL, ENIG, OSP, Plating AG, Plating gold,HAL tin, silver |
20 |
Materials |
FR4,H-TG,Teflon,Rogers,Ceramics,Aluminium, Copper base, CEM-3, CEM-1, Halgenfree |
Competitive Advantage:
1.We provide really good price.
2.We supply very wide range of PCB.
3.We keep 95% on-time delivery by far, and expect a rise in every year.
4.We have no MOQ and provide free samples.
5.All our factories have UL and ISO9001 certificates, we can provide good quality products.
6.We give customer great customer services.
7.We provide Diversified Shipping Method.
8.We do SMT and Thru-hole Assembly.
9.We provide One Stop Turnkey EMS Services
10.We provide quick delivery.
