SR08E/M Wiegand Smart Card Reader
Product Introduction
RFID Wiegand reader as client reader or connect to Access Control Panel via wiegand-out interface.
Features:
· 125KHz Proximity /13.56MHz MF1 Card Reader.
· Read Range: Up to 10CM(125KHz)/5CM(13.56MHz).
· 26/34bit Wiegand (default).
· Easy to install on Metal Door Frame or Mullion.
· External LED Control.
· External Buzzer Contro.
· Indoor / Outdoor Operation.
· Solid Epoxy Potted.
· Waterproof IP65.
· Reverse Polarity Protection.
Technical Specification
| Read Range | SR08ME Up to 10CM; SR08MM Up to 5CM |
| Power / Current | DC 6-14V / Max.70mA |
| Input Port | 2ea (External LED Control, External Buzzer Control) |
| LED Indicator | 2 Color LED Indicators(Red and Green) |
| Beeper | Yes |
| Operating Temperature | -10° to +70°C |
| Operating Humidity | 10% to 90% relative humidity non-condensing |
| Material | ABS+PC with texture 12V DC 3A |
| Dimension | 118*53*22.5mm |
| Weight | 115g |
| Index of Protection | IP65 |
| Reading Time (Card) | ≤300ms |
| Output Format | SR08ME: 26bit Wiegand (default); SRMM: 36bit Wiegand (default) |
Product Photo
