High Density Device Population Flex-Rigid Circuit OEM in China

Name: High Density Device Population Flex-Rigid Circuit OEM in China
Brand: Rayming
SKU: 119058545
Availability: InStock

US$ 0.1 - 20 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Rayming

Model Number:

RMRFP010714

Shenzhen Rayming Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen/Hongkong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Rayming

Model Number RMRFP010714

Base Material PI/FR-4(Tg 145)

Copper Thickness 0.2-6 oz

Board Thickness 0.2-8.5mm

Min. Hole Size 0.20mm

Min. Line Width 0.102(4mil)

Min. Line Spacing 0.102m(4mil)

Surface Finishing ENIG /HASL/OSP/Immersion Gold/Immersion Tin/Immersion Silver

1.MOQ is 1 PCS.

2.PCB Manufacture,PCB/SMT Assembly,PCB Clone.

3.Certificate: UL ,ISO9001,ISO14001.

Welcome to Rayming

Company Overview:

RayMing Technology is a professional PCB Manufacturer.

We have two factories in the city of Shenzhen and JI'An.

	SZ Plant	Ji'An Plant
Loaction	Building A4, Haosan Linpokeng Industrial Zone, ShaJing Town, Bao’An District, Shenzhen	Economy-Technology Development Area Jinggangshan Ji"An city JiangXi Province
Year of Establishment	2003	2008
Plant Area	7,000m²	150,000m²
Monthly Output Capacity	30,000m²	80,000m²
Number of employee	400	1400

Capacity:

Item	Low volume and Mass Volume	Prototype
Layers	1-8	1-20
Max.Panel Size	600770mm (23.6"30.31")	6001200mm (19.69"47.24")
Max board thickness	8.5mm	8.5mm
Min.Board Thickness	0.3mm	0.2mm
Heavy Copper	4oz (140um)	4oz (140um)
Min.Inner Layer Clearance	0.1mm (4mil)	0.1mm (4mil)
Min. Line Width	0.1mm (4mil)	0.075mm (3mil)
Min.Line Space	0.1mm (4mil)	0.075mm (3mil)
Min.Hole Size	0.2mm (7.87mil)	0.15mm (5.91mil)
Min copper plating thickness (min./avg.)	18um/20um	18um/20um
PTH Dia. Tolerance	+/-0.076mm (+/-3mil)	+/-0.076mm (+/-3mil)
NPTH Dia.Tolerance	+/-0.05mm (+/-2mil)	+/-0.05mm (+/-2mil)
Hole Position Deviation	0.05mm (2mil)	0.05mm (2mil)
Min S/M Pitch	0.1mm (4mil)	0.1mm (4mil)
Color of Solder mask	Green (matte/gloss),black,blue,yellow,red,white	Green(matte/gloss),black,blue,yellow,red,white
Color of Silkscreen	White,yellow,red,black	White,yellow,red,black
Outline	Routing,V-groove,Beveling Punch	Routing,V-groove,Beveling Punch
Outline Tolerance	+/-0.15mm (+/-6mil)	+/-0.15mm (+/-6mil)
Impedance Control	+/-10%	+/-7%
Thermal Shock	3*10sec@288℃	3*10sec@288℃
Warp and Twist	≤0.7%	≤0.7%
Electric Strength	>1.3KV/mm	>1.4KV/mm
Peel Strength	1.4N/mm	1.4N/mm
Solder Mask Abrasion	6H	6H
Flammability	94V-0	94V-0
