IE WEB Single Door Access Controller, 1 door / 2 readers
Product Introduction:
DC01-WEB stand alone access control panel is a device combined the most advanced chip technology and mechanics of communication. User can connect the controller with one reader for entry and one button for exit; also it allows to connect one reader for entry and one reader for exit to realize more safer door access control request. It has Built-in Internet Explorer Design; Browser/Server structure; Users don't need to install software and can enter into the management interface directly through internet explorer.
Features:
· Built in Internet Explorer Design; Browser/Server structure; Users don't need to install software and can enter into the management interface directly through internet explorer.
· It adopts 32 bit CPU and can provide fast,stable,convenient and simple operation platform.
· Support offline work; apply TCP/IP communication; allow direct connection with computer via network cable. Support LAN ,remote control, and control by mobilephone through internet.
· It supports multi mother card addition and deletion. With the mother card, user can authorize or cancel privilege of other cards.
· With the search tool it has, this device allows user to set the communication parameters automatically. This could be a big help to those people who don't know how to use internet.
· Compared to standard stand alone access controller, this device separates the reader and the controller to individual parts so to realize higher safety request of your customer.
· This device is compatible with all RF reader which is with any type of Wiegand stantard communication format available in the market. It supports at most 8 groups of password. User can name for each group of password.
· Wrong connection of reader or data cable will not destroy the device or unlock the door illegally.
· Effect inhibition of static electricity and surge from input and feedback interference from electronic locks.
Parameter index:
| Product Parameter | Parameter Description |
| PCB board size | 11.9cm * 7.2cm |
| Case Size | 22.2cm * 16.6cm * 5.5cm |
| Color of case | Milk white |
| Powersupply | 12VDC 4-7A |
| Power | 30W |
| Reader Input Format | Wiegand 26 (compatible with all readers under the agreement, such as Motorola, EM, M1, etc.) |
| Function Description | can control two doors, enter via card swiping and exit via card swipping or button |
| Quantity of reader | 4pcs |
| Open delay time | 0-999 seconds |
| Card User q'ty allowed | 3000 |
| Department quantity allowed | Max 100 |
Product Photo
Product Certification
Our Factory
Our Advantage
1. Professional R&D department, can offer you OEM/ODM services;
2. Professional technique supports and good service;
3. We strictly control the quality and regard it as our base for existence! QC staffs make piece-by-piece checks for all products.
Products are conducted aging test for 72 hours.
4. Our products are chosen high quality materials and ensure the prophase stability.
5. Our products meet ISO, CE, FCC, RoHS certificates;
Our Target
Provide cost-effective products and timely services with the concept of “one store purchasing”, realize win-to-win cooperation!
How to Pay
By T/T, paypal, westerm union, Moneygram, L/C.
How to Deliver
1. Fast way: By express, e.g. DHL, Fedex, UPS, TNT, EMS... take about 3-7 days.
2. Cheap way (small package): By China post, take about 15-70 days.
3. Cheap way: By Air or by Sea shipment for heavy and big goods.
The Warranty
We provide 1~2 years warranty from the date of delivery but lifetime technical support.
