Help CenterCNC Router , Kitchen Cabinet , Door Production
Related Products
Specifications
High production rate;High production quality;
Heavy duty;
Wood cnc router
- Furniture: ideally suitable for processing cabinet door, wooden door, solid wood furniture, panel wood furniture, windows, tables and chairs, etc.
- Other wooden products: stereo box, computer desk, musical instruments, etc.
- Well-suited for processing panel, insulating materials, plastic, epoxy resin, carbon mixed compound, etc.
-Decoration: acrylic, PVC, density board, artificial stone, organic glass, soft metals like aluminum and copper, etc.
- Designed to meet diverse and complicated processing requirements, highly versatile with routing, drilling, cutting, side milling, sawing and other functions.
- Features world top class mechanical and electronic components, e.g. Japanese servo driver and gear reducer, Italian high power automatic tool changing spindle, French low-voltage electrical components, which guarantee stable performance and high finishing quality.
-8-slots carousel tool changer, accurate and rapid tool positioning.
- Vacuum worktable fitted with aluminum alloy bars and suction cups is rigid yet flexible for various configurations. Cropping the full sheet to your ideal size, routing, drilling, sawing, cutting, and milling—multiple functions, all in one. Easy for loading and unloading, spend less time but get more out of it.
-All of these models can be customized according to customer requirements.
Model No. |
MTCNC-1230PTP |
MTCNC-1243PTP |
Travelling size |
1640*3400*250mm |
1640*4660*250mm |
Working size |
1260*3060*80mm |
1260*4320*80mm |
Table size |
1200*3060mm |
1200*4320mm |
Transmission |
X/Y rack and pinion drive,Z ball screw drive |
|
Table structure |
Moveable gantry; suction cups |
|
Spindle Power |
9.0/12.0KW |
|
Spindle speed |
24000 r/min |
|
Travelling speed |
80m/min |
|
Working speed |
20m/min |
|
Tool magazine |
Carousel |
|
Tool slots |
8 |
|
Drilling head |
14 vertical+3 horizontal+2 sawing units/9 vertical+3 horizontal+1 sawing units |
|
Driving system |
Yaskawa |
|
Voltage |
AC380/3PH/50HZ |
|
Controller |
Syntec |
|
