temperature transmitter with RS485,smart temperature transmitter,4-20ma pt100 temperature transmitter
1. Overview
Temperature transmitter using PT100 as the signal measuring element. Amplifier circuit is provided with stainless steel shell, the sensor signals are converted to standard RS485 signal. The whole product is tested by components, semi-finished and finished products and aging rigorously.
The products with good reliability, wide adaptability, flexibility and diversity of products, widely used in petroleum, chemical, metallurgy, electric power, hydrology and other industrial process field temperature measurement and control.
2. Features:
*Protection:IP65
*Corrosion resistance
*Long-term stability
*Impact resistance, shock resistance
3. Specifications:
Measure range |
0~100℃ |
Accuracy |
≤±0.5%FS |
Stability |
≤0.2% /year |
Lead |
Hirschmann |
Power supply |
24V±20% |
Thread |
M27*2 |
Protection |
IP65 |
Ambient temperature |
-30℃~70℃ |
Operating temperature |
-40℃~85℃ |
Relative humidity |
0~80% |
4. Dimension
4.1 Mechanical connection:
Through the pressure tube joint, directly installed in the hydraulic line. In critical applications (such as violent vibration or shock), pressure pipe joint can be mechanically decoupling by micro hose.
4.2 Electrical connection:
1:power+ 2:power- 3:RS485A 4:RS485B
We are the original manufacturer that engaged in the development, sales and
customized service of pressure sensors/transmitters,
digital pressure gauges,level measuring instruments,pressure switch etc.
Any needs,pls contact.
