Drinking Straw Making|Extrusion Machine

Specifications

Drinking Straw Making|Extrusion Machine:
Including extruder, vacuum and water Cooling and shaping machine, take-up and cutter.

Drinking Straw Making|Extrusion Machine :

This single color drinking straw extruding production includes extruder, vacuum and water Cooling and shaping machine, take-up and cutting machine.

Tchnology Parameters:



Model: TPP-D



Capacity: 40-50kg/h



Material: PP, PE



Straw diameter: 2-13mm



Straw length:≥5mm

Configuration list:





Name	quantity
1. Extruder	1 set
2. vacuum and water Cooling and shaping machine	1 set
3.take-up and cutting machine	1 set
4. mould	1 set































1.Single Screw Extruder

Screw diameter: 50mm



Power: 7.5kw



Heating method: electric heating

2. vacuum and water Cooling and shaping machine



Material: stainless steel



Length: 3500mm( can be ordered design)



Cooling method: water cooling



Drying method: air-sweeping type

3.Take-up and cutting machine

Take-up roller: PU modified rubber



Take-up Power: 0.75kw



Cutting method: rotary cutting



Cutting power: 0.75kw
