Automatic Dustless Chalk Production Line for Making Dustless Chalks

Product name

Technical parameters

description

1. Mixer

Machine

Model: TPP-JB100

Hopper capacity: 100L

Mixing speed: 35/22rpm

Power: 5.5kw

Weight:1000kg

Dimension:2300*1000*

1000mm

Material touching part is made of stainless steel, and it can ensure the product purity and quality.

This model adopts double screws to mix the material, which can make the material homogeneous mixing.

2.Dustless

chalk

extruder

Model: TPP-JC100

Screw diameter: 100mm

Screw rotating speed: 28-200rpm

Power: 4.5kw

Weight:900kg

Dimension:2000*900*

1450mm

1. This machine is horizontal triaxial structure. It adopts continuously viable conveying. The producing speed can be adjusted according to the customers' demands.
2. The extruder parts includes screw rod, screw leaf and screw groove. There is hard ally steel sheet in the easy-broken part to prolong the service life of the machine.
3. Chalking touching part is made of stainless steel.
4. The chalk material tube and vacuum working room are both adopted open-type device, which is convenient to exchange the chalk raw material and maintain.
5. This extruder can be for round shape and kinds of models of chalks.

3.Conveyor

Model: TPP-CS100

Size: 2000*580mm

rotating speed: 0-5m/min

material: PVC

Weight:300kg

Dimension:2300*1000*

1000mm

1. The whole machine is made of high-strength aluminum alloy structure, very durable.

2. Conveyor speed can be adjustable

3. Both sides adopt hand wheel, which is more convenient for adjusting.

4. Stainless steel Chalk Cutter

Model: TPP-QD100

Material: stainless steel

Cutter blades thickness: 0.5mm

Weight: 80kg

Dimension: 1300*900*1000mm

This cutting machine adopts stainless steel cutting blades; the processed chalks are very uniform.

5.Infrared Ray Drying Machine

(this machine is optional according to customers’ demand)

Model: TPP-HG100

Temperature control: 30-120°C

Weight: 1000kg

Dimension: 3800*1700*2560mm

1. This machine adopts radiation heating and automatic temperature controlling system.

2. Temperature rising is very quickly, so it can shorten the drying time.

6.Chalk drying tools

Material: wood

Size: 900*450*60mm

Putting the chalks on the tools for drying by air and sun
